Smart-AVI SKMN-8S-P Secure 8-Port USB KM Switch with Audio Support and Dedicated CAC Port
  • Smart-AVI SKMN-8S-P Secure 8-Port USB KM Switch with Audio Support and Dedicated CAC Port
  • Smart-AVI SKMN-8S-P Secure 8-Port USB KM Switch with Audio Support and Dedicated CAC Port
  • Smart-AVI SKMN-8S-P Secure 8-Port USB KM Switch with Audio Support and Dedicated CAC Port
  • Smart-AVI SKMN-8S-P Secure 8-Port USB KM Switch with Audio Support and Dedicated CAC Port

Questions? Ask a Markertek Expert:
800-522-2025 Email

Smart-AVI SKMN-8S-P Secure 8-Port USB KM Switch with Audio Support and Dedicated CAC Port

Manufacturer: Smart-AVI

Item #: SAVI-SKMN-8S-P   •   MFG #: SKMN-8S-P



List Price:$1,150.00
Our Price:$934.37

free ship


Availability: Direct Ship From Manufacturer
i
Item ships directly from the manufacturer. Normal delivery time is 2-7 business days and is subject to manufacturer availability. Need it sooner? Call 800-522-2025, or email Customer Service for expedited delivery options.


  • 2 - 7 Day Normal Delivery Time - Faster Shipping Options at Checkout or Call Us.


Share!





The Smart-AVI SKMN-8S-P allows users to control KM (keyboard and mouse) operation on up to eight computers. It features mechanical, electrical and optical signal isolation to prevent hacking and data leakage in environments where security is paramount.

With the SKMN-8S-P, all data relays are controlled by inverted signals, shielding connections from outside intrusion by forcing them each to work one at a time. Each port uses its own isolated data channel and each unit features non-reprogrammable ROM to better protect the switch’s functions. Better yet, the SKMN-8S-P offers the highest security when accessing classified and public networks over the internet through these isolated connections. By isolating connections between networks, the SKMN-8S-P ensures no data is leaked between secure ports and the outside world.

The SKMN-8S-P has clearly marked front-panel buttons for controlling the device, so securely switching between sources is always simple. For high-grade secure switching made easy, look no further than the SKMN-8S-P.


  • Features

    • Key Features
    • Supports Windows, Mac and Linux OS
    • Supports Balanced speakers output and switching
    • Advanced configurable CAC port
    • Front panel tactile buttons with LED indicator
    • External power supply - Level VI efficiency
      Security Features
    • Non-reprogrammable ROM
    • Active Anti-tamper switches
    • Long-life internal Anti-tampering battery
    • External tamper-evident seals
    • Keyboard, Mouse and Video emulation
    • Absolute isolation - No data leakage between ports
    • Certified by NIAP, the latest Common
    • Criteria (Protection Profile for Peripheral Sharing Switch Version 3.0)

  • Specifications

    • USB
    • Input Interface: (16) USB Type B
    • Output Interface: (2) USB 1.1 Type A for KM devices
    • Emulation: Keyboard and Mouse
    • CAC: Configurable CAC port
      AUDIO
    • Audio Input: (8) 3.5mm stereo audio
    • Audio Output: (1) 3.5mm stereo audio
      CONTROL
    • Front Panel: Front panel SELECT buttons
      OTHER
    • Power: External 100-240 VAC/ 12VDC3A @ 36W
    • Dimensions: 17" W x 1.76" H x 8.69" D
    • Weight: 6.3 lbs
    • Approvals: NIAP PP 3.0, UL, CE, ROHS Compliant
    • Operating Temp.: +32 to +104°F (0 to +40°C)
    • Storage Temp.: -4 to 140°F (-20 to +60°C)
    • Humidity: Up to 80%
