SmallHD Mon-Cine 13 Full HD 13-Inch 4K High-Bright Monitor with 338 PPI Display

MON-CINE-13 - Overview

• Features:

  • 13.3in / 34cm IPS LCD
  • 1500+nits Brightness
  • 3840x2160 Resolution
  • 100% Rec 709 Color
  • Weight: 6.8lbs / 3.09kg (with handle & feet)


• Specifications:

  • Display:
  • Diagonal Size: 13.3
  • Resolution: 3840x2160
  • Brightness: 1500nits
  • Contrast: 1300:1
  • Gamut: 100% REC.709
  • Color Depth: 10-bit (8+2)
  • Backlight Type: Edgelit
  • Display Size: 13"
  • Panel Resolution: 3840 x 2160
  • Brightness: 1500nits
  • Color Bit Depth: 10-bit (8+2)
  • Backlight Type: Edge-Lit
  • DCI-P3 Color: 100% REC.709

    EVF:
  • Height (in): 10.1 (w/out feet and handle) 12.4 (w/ feet and handle)
  • Width (in): 13.2 (w/out feet and handle) 13.2 (w/ feet and handle)
  • Depth (in): 2.3 (w/out feet and handle) 4.7 (w/ feet and handle)
  • Weight: 6.8lbs/3.09kg

    Input Signal:
  • 12G-SDI Input Types: 4x 12G-SDI
  • HDMI Input Types: 1x HDMI 2.0 (4K60)

    Output Signal:
  • 12G-SDI Output Types: 4x 12G-SDI
  • HDMI Output Types: Coming Soon
  • Audio Output Types: 1x 3.5mm 3-pin Stereo Headphone Jack(coming soon)

    Data I/O:
  • Connector Type: 1x SD Card Slot, 1x RJ45 Ethernet, 1x RJ45 GPI

    Power:
  • Input: 1x XLR 4-pin 12 - 34VDC IN (210W max, 12V-34V, 18A max)
  • Output: 2x 2pin (12V / 2A combined) 1x USB (2.4A) (Front) 1x USB (1.5A) (Front) 1x USB-C (5V / 1.5A)
  • Consumption: 36.7w (monitor only) 117.9w (w/max access. power draw)
  • Battery Plate Included: No
  • Battery Types: 1x Dual-GM/VM Batt.Plate (14/26V) (sold as accessory)


• Item Includes:

  • 1x SmallHD MON-CINE 13
  • 1x 4K HDMI to 4K HDMI Cable (120 Inch)
  • 1x SmallHD 4K Monitor Feet (Set)
  • 1x 8GB SD Card
  • 1x SmallHD Cleaning Cloth
  • 1x Basic Acrylic Locking Screen Protector
  • 1x Power Supply


• GTIN:

  0811786032136
