Sony BRC-X1000 4K PTZ Camera with 1-Inch Type Exmor R CMOS Sensor

ITEM #: SNY-BRC-X1000 MFG #: BRC-X1000

  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
free ship

List Price:

$9,899.00

Our Price:

$8,300.00

Availability: Extended Lead Time. Email, Chat or Call Us for more details.
iAvailability Description Popup


    BRC-X1000 - Overview

    The BRC-X1000 is Sony's first 4K remote camera, combining uncompromising broadcast picture quality and smooth, silent PTZ operation with the flexibility of 3G-SDI and HDMI connections.

    Designed for remote operation, this compact but powerful robotic camera is an ideal complement to other broadcast cameras for capturing images in hard-to-reach or unobtrusive positions. It's equally at home in TV newsrooms, remote studios and on-air suites, auditoriums, houses of worship, courtrooms or sports stadiums. It's also particularly suited to efficient multi-camera set-ups, under the control of a single operator.

    The 1-inch type Exmor R CMOS image sensor captures detail-packed 4K footage at 30p with four times the pixel count of Full HD, and excellent low-light sensitivity. The large image sensor also allows the creation of beautiful 'bokeh' effects with a shallow depth of field to suit any artistic intention.

    Speedy, near-silent PTZ operation with 12x optical zoom accommodates wide-angle scenes and tightly framed close-ups, with Clear Image Zoom 18x (4K), 24x(HD) extending this range even further without visible loss of resolution. Broadcast-friendly features include dual tally lamps for on-air operation, while operational flexibility is enhanced with options for ceiling, table top or tripod mounting.

    There's also a broad range of video interfacing and remote control possibilities - plus support for PoE+ and genlock - for smooth integration into any broadcast, professional or corporate AV environment.

    • Features:

      • Enhanced Pan/Tilt/Zoom (PTZ) operation
      • Uncompromising 4K images
      • Cinematic 24p pictures
      • High quality 12x optical zoom and 18x(4K) or 24x(HD) with Clear Image Zoom
      • Excellent low light sensitivity
      • Flexible installation
      • Remote operation
      • Genlock
      • Versatile video outputs
      • Front and rear tally lamps
      • Always up to date

    • Specifications:

      • Image Sensor: 1.0-type back-illuminated Exmor R CMOS sensor
      • Image Sensor (Number of Effective Pixels): Approx. 14.2 Megapixels
      • Image Sensor (Total Number of Pixels): Approx. 20.4 Megapixels
      • Signal System: 2160/29.97p, 1080/59.94p, 1080/59.94i, 720/59,94p, 2160/25p, 1080/50p, 1080/50i, 720/50p
      • Minimum Illumination (50IRE): 1.7 lux (50IRE, F2.8, 1/30s, Max.Gain)
      • Horizontal Resolution: 1800 TV line (in 3G-SDI output) (center)
      • Gain: Auto/Manual (-3dB to +33dB)
      • Shutter Speed: 1/10000s to 1/8 (59.94/29.97), 1/10000s to 1/6 (50/25)
      • Exposure Control: Auto, Manual, Priority mode (shutter priority, iris priority, gain priority), Back light, Spot light
      • White Balance: Auto1/Auto2/One Push/Indoor/Outdoor/Manual
      • Optical Zoom: 12x
      • Clear Image Zoom: 2x, 1.5x at 4K resolution
      • Digital Zoom: No
      • Focusing System: Auto/Manual
      • Horizontal Viewing Angle: 64.6° (Wide-end)
      • Focal Length: f=9.3 to 111.6mm, F2.8(Wide) ,F4.5(Tele)
      • Minimum Object Distance 1000mm(Tele), 80mm(Wide)
      • Pan/Tilt Angle-
      • Pan: ±170°
      • Tilt: +90°/-30°
      • Pan/Tilt Speed-
      • Pan: 0.3° to 60°/s
      • Tilt: 0.3° to 60°/s
      • Pan/Tilt Slow Mode: Yes
      • Preset Position: 16
      • 4K Video Output: Dual Link 3G-SDI(2SI only) x2 and HDMI
      • HD Video Output: 3G-SDI x4 and HDMI
      • HDMI Color Space: YCbCr, 4:2:2 / RGB, 4:4:4
      • Camera Control Interface-
      • VISCA RS-422
      • RJ45(In/Out)
      • VISCA over IP
      • RJ45
      • External Sync. Input: BNC, 75Ω, HD 3-level sync, SD Black Burst
      • Power Connector Type: IEC60130-10 (JEITA standard RC-5320A), TYPE4
      • Power Requirements: DC 10.8V to 13.2V, PoE+ (IEEE802.3at compliant)
      • Power Consumption: DC12 V:21.5 W (Max), PoE+:25.5 W (Max)
      • Operating Temperature: 32 °F to 104 °F
      • Storage Temperature: -4 °F to +140 °F
      • Dimensions (W x H x D): Approx. 7 7/8 x 10 1/4 x 9 3/8 inch (without projecting object)
      • Mass: Approx. 9 lb 7.7oz
      • Optional Card Slots: Not needed
      • Body Color: Black
      • Size of Screw Hole for Tripod: 1/4-20UNC x2
      • Mountable Angle: <±15°
      • Ceiling Mount: Yes

    • Item Includes:

      • IR Remote Commander Unit (1)
      • Ceiling bracket (2)
      • Wire rope (1)
      • Screws(M3 x 8) (7)
      • Screws(M4 x 8) (1)
      • HDMI cable fixing plate (1)

    • GTIN:

      0027242285866
