StarTech POEINJ1G90W Industrial-Grade Hardened PoE Injector - 1G 802.3bt - 90 Watt Max

ITEM #: ST-POEINJ1G90W MFG #: POEINJ1G90W

  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
free ship

Our Price:

$280.99

Availability: Typically Ships in 3-10 Days
iAvailability Description Popup


    POEINJ1G90W - Overview

    This Gigabit Power over Ethernet (PoE+) injector supplies power and data connectivity to a Gigabit PoE-compliant device using a standard Ethernet cable.

    Flexible Configurations for a Variety of Applications
    Compatible with IEEE 802.3bt and most previous 90W proprietary PoE (Ethernet) standards, including PoH (HDBaseT), Cisco uPoE, Bosch, and AXIS. One product can cover multiple use requirements to improve standardization and deployment and dual power terminal block inputs provide redundancy for critical applications.

    90 Watt Power Budget
    As many typical PoE-enabled switches max out at 30W a high 90W power budget is perfect for demanding Type 3 and Type 4 PoE applications like tilt and pan cameras and high power IEEE 802.11ax wireless access points.

    • Features:

      • Wide Standard Compatibility
      • 90W Power Budget
      • Robust Design
      • 2 Year Warranty

    • Specifications:

      • Connector(s):
      • 1 - Connector Type(s): Ethernet Gigabit, RJ-45 (PoE+), Terminal Block (4 Wire)

        Environmental:
      • Operating Temperature: -40°C to 75°C
      • Storage Temperature: -40°C to 85°C
      • Humidity: 5 to 95% (non-condensing)

        Hardware:
      • Ports: 2
      • Industry Standards:
        IEEE 802.3 10BASE-T
        IEEE 802.3u 100BASE-TX
        IEEE 802.3ab 1000BASE-T
        IEEE 802.3at PoE Plus
        IEEE 802.3af Power over Ethernet
        IEEE 802.3bt
      • Chipset ID: Microsemi PD69204

        Indicators:
      • 2 - LED Indicators: Power, PoE

        Packaging Information:
      • Package Height: 2.5 in [6.4 cm]
      • Package Length: 6.4 in [16.2 cm]
      • Shipping (Package) Weight: 14.7 oz [416.0 g]
      • Package Width: 8.3 in [21.1 cm]

        Performance:
      • Maximum Cable Length: 328.0 ft [100 m]
      • Surge Protection: 2kV
      • Compatible Networks: 10/100/1000 Mbps
      • Auto MDIX: Yes
      • Full Duplex Support: Yes
      • Jumbo Frame Support: 9K max.

    • Item Includes:

      • 1x Industrial-Grade PoE Injector
      • 1x Terminal Block
      • 1x Mounting Hardware Kit
      • 1x Quick-Start Guide

    • GTIN:

      0065030889568
