    WCG3-4K-HDMI-610 - Overview

    The Telestream WCG3-4K-HDMI-610 Wirecast Gear 3 is a 4K-HDMI professional streaming device.

    A future-proof solution, the Wirecast Gear 3 allows for broadcast industry-leading, high-quality video through 4 4K60 HDMI input sources, plus a 1080p60 3G-SDI input and output, into your content production workflow. Get all of the powerful features and functionality included in Gear 3 HD models, but with faster GPU acceleration for enhanced flexibility and creative control.

    Wirecast Gear Family
    Wirecast Gear 3 is a family of turnkey live video streaming and broadcast production appliances. Fully integrated into a single device, Gear 3 provides plug-in-and-go live-streaming and video production for up to five HD or 4K SDI, or four HDMI, sources. Live sports, news broadcasting, worship streaming, and live/ virtual event production is now available in one ready-to-go, convenient, rack-mountable unit.

    Every Gear 3 unit comes with an ultra-fast AMD Ryzen six-core processor, NVIDIA Quadro GPU for acceleration and encoding, Wirecast Pro software with Stock Media Library for video production and switching, and Switch Player to inspect and monitor the quality of your content. Built as a flexible Windows machine, Gear also supports common applications such as Microsoft Teams, Zoom, Adobe Creative Cloud, and more as the most comprehensive, configurable, and professional hardware appliance in its class. Elevate event production with ease and without stress when you take advantage of our top-of-the-line Wirecast Gear.

    • Features:

      • AMD Ryzen 5 6-core/12-thread processor
      • NVIDIA Quadro GPU for acceleration and encoding
      • 16GB System Memory
      • 9 USB 3.1 (incl. rear USB-C & dual front-mounted USB-A)
      • 1TB SATA3 SSD Storage Drive

    • Specifications:

      • Hardware Internal Configuration
      • CPU: AMD Ryzen 5 5600X 6-core/12-thread 4.6GHz (max)
      • Motherboard Chipset: AMD X570
      • GPU: NVIDIA Quadro T400 (HD models) / T1000 (4K models)
      • Memory: 16GB DDR4-3200
      • System Drive: 250GB NVMe M.2
      • Storage Drive: 1TB SATA3
      • USB: USB 3.1 Gen 2 (1x USB-C rear + 4x USB-A rear), USB 3.1 Gen 1 (2x USB-A front, 2x USB-A rear)
      • Network: 2xRJ-45 IEEE 802.3ab Gigabit Ethernet
      • Audio: 2-ch Line In/Out, Mic In/Out + Front Line Out / Mic In +
      • Ls/Rs/Lb/Rb/C/S

        Video Inputs and Outputs
      • Display Output - Wirecast Gear 3 4K HDMI: 4x Mini DisplayPort 1.4 3840x2160 @ 60Hz max + 1x 3G-SDI SMPTE 422M, 1920x1080 @ 60Hz max
      • Capture Input - Wirecast Gear 3 4K HDMI: 4x HDMI 2.0b (non-HDCP) 3840x2160 @ 60Hz 4:4:4 max

        Physical
      • Dimensions: 16.7 x 12 x 3.5", 2RU x 19" w/handles
      • Weight: 14.5-15.5 lb. (unit only)

        Power
      • Input Voltage: 90VAC-264VAC RMS Single Phase 47Hz-63Hz
      • Input Current: 8A @ 115VAC 60Hz RMS, 4A @ 230VAC 50Hz RMS, Single Phase
      • Input Connection: IEC 60320 C14 3-pin
      • Operating Temperature/Humidity: 32 - 104 F @ 20-80% (operating), -4 - 185 F @ 10-90% (storage)

    • Item Includes:

      • 1x Wirecast Gear 3 4K HDMI Professional Streaming Device
      • 1x Power cable
      • 1x Wireless keyboard
      • 1x Wireless mouse
      • 1x USB dongle for both the keyboard and mouse
      • AA batteries for both the keyboard and mouse

    • Warranty:

      • I Year

    • GTIN:

      0072527274972
