Thor Fiber H-HDMI-E/D 1080p HDMI Over IP Streaming Encoder/Decoder Kit - 120 Meters Over CATx

ITEM #: THR-H-HDMI-E-D MFG #: H-HDMI-E/D

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the THR-H-HDMI-E-D

H-HDMI-E/D - Overview

The Thor Broadcast H-HDMI-E/D is an IP Streaming Encoder/Decoder which uses H.264 protocol to extend HDMI video, IR and RS232 control signals over IP networks. It works with one control PC (Wake on LAN) and one switch whose transmission rate is 100Mbps or higher to control a variety of functions. The H-HDMI-E/D features 1080p HDMI video switching, video wall, video live preview, audio de-embedding, audio switching, IR&RS232 transmission, video recording, PoE, etc. The controlling software, "IP Streaming Management" merges all functions for you to control the IP streaming system.

  • Features:

    • H.264 encoding and decoding
    • 1080p video over IP network with IR and RS232 control
    • 120m over CATx cable (cat cable distance varies based on the cable)
    • Video extension, video distribution and video matrix
    • Output video scaling to 720p or 1080p
    • Both units are PoE, Encoder/Decoder can be powered by PoE Switch
    • Live Video Preview on the GUI
    • Video Broadcasting over network
    • Video recording
    • The encoder features an HDMI loop out.
    • Includes audio breakout.
    • Protocols include RTSP, RTP, HTTP, FLV, UDP, and TCP
    • Unicast and Multicast.


  • Specifications:

    • Decoder
    • Video-Input: HDMI IN
    • Video-Input Connector: Type A female HDMI
    • HDMI Input Resolution: Up to 1080p@60Hz 444 10/12bit
    • Video Output: HDMI Out
    • Video Output Connector: Type A female HDMI
    • HDMI Output Resolution: Up to 1080p@60Hz 444 10/12but
    • Control: RS232, IR In, IR Out, LAN (PoE)
    • Control Connector: 3-pin terminal block, 3.5mm jack, RJ45

      Encoder
    • Video Output: HDMI Out
    • Video Output Connector: Type A female HDMI
    • HDMI Output Resolution: Up to 1080p@60Hz 444 10/12bit
    • Audio Output: Audio Out (L+R)
    • Audio Output Connector: RCA jack
    • Control: Storage, RS232, IR In, IR Out, LAN (PoE)
    • Control Connector: Type-A USB, 3-pin terminal block, 3.5mm jack, RJ45

      General
    • Video ENcoding Standard: H.264
    • CATx Cable Length: Up to 120 meters
    • External Power Supply: Input: AC 100-240V, 50/60Hz, Output 12VDC 1A, PoE
    • Power Consumption: Encoder: 4W(Max) ; Decoder: 3.5W (Max)
    • Operation Temperaturre: -5CΩ - +55CΩ
    • Storagge Temperature: -25CΩ - +70CΩ
    • Relative Himidity: 10% - 90%
    • Dimension (W*H*D): 152.0mm x 21.0mm x 100.0mm
    • Net Weight: Encoder: 340g ; Decoder: 345g


  • Item Includes:

    • 1x Thor Fiber H-HDMI-E/D 1080p HDMI Over IP Streaming Encoder/Decoder Kit - 120 Meters Over CATx
