TRENDnet TPE-TG82ES 8-Port Gigabit EdgeSmart PoE+ Switch with 64W PoE Power Budget

ITEM #: TNET-TPE-TG82ES MFG #: TPE-TG82ES

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$150.37

Our Price:

$135.33

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    TPE-TG82ES - Overview

    TRENDnet's 8-Port Gigabit EdgeSmart PoE+ Switch, model TPE-TG82ES, is a cost-effective desktop PoE managed switch solution for high-speed gigabit PoE+ applications. This EdgeSmart switch features the most commonly used managed switch features, reducing unnecessary switch complexity. The web-based management interface offers features for traffic control, static link aggregation, RSTP, VLAN, QoS, and monitoring. TRENDnet's TPE-TG82ES desktop PoE managed switch provides eight gigabit PoE+ ports for connecting devices such as wireless access points, IP cameras, and VoIP handsets.

    EdgeSmart Management
    Provides an easy-to-use web-based management interface for reduced switch configuration complexity and offers a combination of more commonly used SMB management features for easy deployment.

    Integration Flexibility
    Managed features include loopback detection, RSTP, static link aggregation, VLAN, IGMP Snooping, and QoS for flexible network integration.

    PoE+ Power
    A 64W PoE power budget supplies up to eight Power over Ethernet devices.

    • Features:

      • 8 x Gigabit PoE+ ports
      • 64W PoE power budget
      • Easy-to-use web-based management interface
      • Supports static link aggregation, RSTP, VLAN, QoS, and IGMP Snooping
      • Voice VLAN for VoIP applications
      • Bandwidth control per port
      • 16Gbps switching capacity
      • IEEE 802.1p CoS with queue scheduling support
      • Compact fanless design
      • Wall mountable metal housing

    • Specifications:

      • Standards: IEEE 802.1d, IEEE 802.1w, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az
      • Device Interface: 8 x Gigabit PoE+ ports, LED indicators, Reset button
      • Data Transfer Rate: Ethernet: 10Mbps (half duplex), 20Mbps (full duplex), Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex), Gigabit Ethernet: 2000Mbps (full duplex)
      • Performance: Switch fabric: 16Gbps, RAM buffer: 192KB, MAC Address Table: 4K entries, Jumbo Frames: 9KB, Forwarding rate: 11.9Mpps (64-byte packet size)
      • Management: HTTP Web based GUI, SNMP v1, v2c, Cable diagnostic test, Backup/Restore Configuration, Upload Firmware
      • Spanning Tree: IEEE 802.1d STP (spanning tree protocol), IEEE 802.1w RSTP (rapid spanning tree protocol)
      • Link Aggregation: Static link aggregation (up to 2 groups)
      • Quality of Service (QoS): Port-based QoS, 802.1p Class of Service (CoS), Bandwidth Control/Rate Limiting per port (Min. Limit: 8Kbps), Queue Scheduling: Strict Priority (SP), Weighted Fair Queueing (WFQ)
      • VLAN: Port-based VLAN, 802.1Q Tagged VLAN, Up to 32 VLAN groups, ID Range 1-4094, Private VLAN, Asymmetric VLAN, Voice VLAN (5 user defined OUIs)
      • Multicast: IGMP Snooping v1/2/3, Block unknown multicast source, Up to 32 multicast groups
      • Port Mirror: One to one, Many to one
      • Storm Control: Broadcast (Min. Limit: 8Kbps), Multicast (Min. Limit: 8Kbps), Loopback Detection
      • Special Features: PoE+ support, Enable/disable 802.3az Power Saving, Wall mountable
      • Power: Input: 100 - 240V AC, 50/60Hz, 1.2A, Output: 54V DC, 1.67A external power adapter, Max. consumption: 68.6W
      • PoE: PoE budget: 64W, 802.3at: Up to 30W per port, PoE Mode A: Pins 1,2 for power and pins 3,6 for power, PD auto classification, Over current/short circuit protection
      • Fan / Acoustics: Fanless design
      • MTBF: 730,455 hours
      • Operating Temperature: 0° - 40° C (32° - 104° F)
      • Operating Humidity: Max. 90% non-condensing
      • Dimensions: 171 x 97.8 x 28.6mm (6.73 x 3.85 x 1.12 in.)
      • Weight: 423g (14.92 oz.)
      • Certifications: CE, FCC

    • Item Includes:

      • 1x TPE-TG82ES
      • 1x Quick Installation Guide
      • 1x Power adapter (54V DC, 1.67A)

    • Warranty:

      • 3 year
