Newtek Spark Plus I/O 12G-SDI to NDI Converter

SPARK PLUS I/O 12G-SDI - Overview

• Features:

  • Compatible With Any NDI® Workflow: Share video over IP with any compatible system, device, or application that supports NDI, including NewTek solutions and products from third-party manufacturers and developers.
  • NDI® Transfer Modes: Transmit video to your network using your choice of supported NDI transfer modes, to include unicast and multicast UDP with forward error correction (FEC), and unicast TCP.
  • NDI® Input and Output: Acquire video from connected devices such as cameras and deliver as IP to networks with NDI or provide IP with NDI from networks to destinations such as displays.
  • Connectivity: Send and receive video with networks via Ethernet and be instantly available as NDI® sources and endpoints for any compatible system, device, or application.
  • Portable and Mountable: Carry NewTek Spark™ Plus video converters with you wherever you go, or optionally mount to a compatible camera or support using the industry-standard threaded screw mount.
  • Audio: Present high-quality audio with support for analog and embedded digital sources.
  • Program and Preview Tally: Receive tally notification from compatible NDI® devices via a physical LED when video output from any NewTek Spark™ Plus product is visible on Program and/or Preview.
  • NDI® Virtual Input: Designate your video input source in popular desktop video applications like Google Hangouts, GoToMeeting, Skype, Skype for Business, WebEx, Zoom, and more using the NDI® Virtual Input tool. * NDI Virtual Input included with NewTek NDI Tools download at no charge.
  • Web-Based Interface: Monitor video, manage login credentials, access recording controls, and configure audio, video, and network settings from any supported Web browser on any compatible networked device.
  • Multicast Mode: Permit multiple destinations as an option to receive your video source without individual point-to-point connections to conserve network bandwidth.
  • Network Identification: Easily identify devices on your network with the ability to apply custom device and channel names.
  • Network Visibility: Access devices connected to other networks via IP address and make them visible within your production environment using NDI® Access Manager.
  • Firmware Updates: Download and install firmware updates at no charge with the latest features, capabilities, and performance enhancements.


• Specifications:

  • Video Input: 1x 12G-SDI
  • Video Output: 1x 12G-SDI
  • Audio Input: 3.5mm Analog Stereo Line Level Embedded 12G-SDI
  • Audio Output: 3.5mm Analog Stereo Line Level Embedded 12G-SDI
  • Encoding/Decoding: NDI®
  • Network: 1 x RJ-45 port Gigabit Ethernet
  • Interface: Web-based user interface for configuration and monitoring
  • Tally: Tally support via NDIr
  • Formats:
    2160p: 59.94, 50, 29.97, 25
    1080p: 59.94, 50, 29.97, 25
    720p: 59.94, 50, 25
  • SDI: 75 Ohm impedance SMPTE ST-424M, ST-292M
  • Power: Power over Ethernet or External Power Adaptor DC 5V~18V Power Supply
  • Physical: Portable enclosure with threaded screw camera mount
  • Dimensions: 4.33 x 3.7 x 1.1" (110 x 95 x 28 mm)
  • Weight: .66 lbs (.30kg)
