Ubiquiti U7-LITE Compact Ceiling-Mounted WiFi 7 Access Point with 4 Spatial Streams and 2.5 GbE Uplink

U7-LITE-US - Overview

• Features:

  • Wireless Meshing
  • Band Steering
  • 802.11v BSS Transition Management
  • 802.11r Fast Roaming
  • 802.11k Radio Resource Management (RRM)
  • Advanced Radio Management
  • Passpoint (Hotspot 2.0)
  • Custom Branding Landing Page
  • Voucher Authentication
  • Payment-Based Authentication
  • External Portal Server Support
  • Password Authentication
  • Guest Network Isolation
  • Private Pre-Shared Key (PPSK)
  • WiFi Speed Limiting
  • Client Device Isolation
  • WiFi Schedules
  • RADIUS over TLS (RadSec)
  • Dynamic RADIUS-assigned VLAN


• Specifications:

  • WiFi Standard: WIFi 7
  • Spatial Streams: 4
  • Coverage Area: 1,250ft² (115m²)
  • Max. Client Count: 200+
  • Uplink: 2.5GbE
  • Mounting: Ceiling, Wall (Lite Mount Included)
  • Power Method: PoE
  • Max. Data Rate: 5GHz - 4.3Gbps (BW240), 2.4GHz - 688Mbps (BW40)
  • Antenna Gain: 5GHz - 5dBi, 2.4GHz - 4dBi
  • Max. TX Power: 5GHz - 24dBm, 2.4GHz - 23dBm
  • Max. BSSIDs: 8 per Radio
  • Supported Data Rates:
    - 802.11be (WiFi 7) - 7.3Mbps - 4.3Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)
    - 802.11ax (WiFi 6) - 7.3Mbps - 2.4Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
    - 802.11ac (WiFi 5) - 6.5Mbps - 1.7Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
    - 802.11n - 6.5Mbps - 300Mbps (MCS0 - MCS15, HT 20/40)
  • Max. Power Consumption: 13W
  • Supported Voltage Range: 42.5V - 57V DC
  • Networking Interface: 1x 2.5 GbE RJ45 port
  • Weight: 11oz (313g)
  • Management: Ethernet
  • Enclosure Material: UV-stabilized polycarbonate
  • Mount Material: UV-stabilized polycarbonate, galvanized steel (SGCC)
  • System LEDs: White/Blue
  • Channel Bandwidth: HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 (MHz)
  • Ambient Operating Temperature: -22°F - 104°F (-30°C - 40°C)
  • Ambient Operating Humidity: 5% - 95% noncondensing
