Netgear WAX630-100NAS Tri Band Wi-Fi 6Gb/s Indoor Wireless Access Point - Ceiling/Wall Mountable - White

ITEM #: NG-WAX630100NAS MFG #: WAX630-100NAS

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$545.96

Our Price:

$379.99

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


WAX630-100NAS - Overview

Netgear's WAX630-100NAS is the industry's highest performance WiFi 6 access point for the small and medium size businesses. The access point is a tri-band 4x4 design delivering up to 6Gbps total WiFi through-put, supported by a 2.5Gbps Power-over-Ethernet port, an industry leader of performance and cost effectiveness in its product class. The WAX630 supports the next generation WiFi 6 smart phones, IoT
devices, and notebook computers, delivering up to 40% more throughput to each individual device in the 5GHz band and 100% more throughput in the 2.4GHz band, compared to the previous generation equivalent model; provides 4x the client device connection, allowing businesses to serve more customers with better speed and less congestion.

The WAX630 is ideal in high density client device environments such as schools, hotels, restaurants and conference centers, and provides enterprise grade WiFi network security. With Insight management, WAX630 works seamlessly with your current NETGEAR Insight managed switches, WiFi access points and network Ultimate Performance WiFi 6 Access Point Insight WAX630 for the Small and Medium Size Businesses storage, and is compatible with previous generation WiFi devices (WiFi 5 802.11ac for example) and WiFi access points. Enjoy a 1-Year Insight subscription included with WAX630.

The WAX630, a WiFi 6 business access point, combined with Insight, helps small and medium businesses with an easy way to manage their network without an IT expert, providing great WiFi connection leaving each of their customers satisfied as a network user. NETGEAR empowers businesses with an all new WiFi 6 business access point for high performance and high coverage for the years to come.

The WAX630 is compatible with other Pro WiFi Insight managed access points to form a scalable wireless network.

  • Features:

    • Business class WiFi based on next generation 802.11ax WiFi 6 technology on both 5.0GHz and 2.4GHz bands. (Backward compatible to 802.11b/g/n/a/ac)
    • Tri-band 4x4 (2.4GHz, 5.0GHz Low, 5.0GHz High) 12 streams of data for an aggregate throughput of up to 6.0Gbps
    • Instant WiFi Mesh forming wireless backhaul with other Pro WiFi Insight managed access points to form a WiFi mesh network
    • 40% more throughput in 4-stream 5.0GHz band and 100% more throughput in 4-stream 2.4GHz band compared to previous generation
    • 4 times more client device supported
    • Enterprise security and Enhanced Open security, such as WPA3, WPA2 Enterprise, WPA3 Enterprise, 8x SSID and VLAN
    • Basic Service Set Coloring (BSS Coloring) enabling significant improvement in radio frequency channel effeciency and reduction of interference
    • Orthogonal Frequency Division Multiple Access (OFDMA) allowing simultaneous services to multiple devices in the same channel thus improving bandwidth efficiency and reducing latency
    • 2.5GbE port, backward compatible with 100/1000Mbps Ethernet, supported by NETGEAR MS510TXUP and other multigig Ethernet switches
    • One additional 1GbE port for network redundancy or link aggregation to enhance reliability or throughput
    • Target Wake Time (TWT) allows more efficient power usage resulting in longer battery life in WiFi 6 client devices
    • Beamforming+; Advanced 6th generation WiFi technology such as up and downstream MU-MIMO
    • One 802.3bt 2.5Gbps PoE port
    • Remote management and monitoring from NETGEAR Insight app or Cloud portal for unrivaled management experience of your wireless network
    • Faster installation through NETGEAR Insight app or Cloud portal

  • Specifications:

      General
    • Wi-Fi Standards:
      - 5.0GHz: 802.11a/n/ac/ax
      - 2.4GHz: 802.11b/g/n/ax
    • Wireless Mode (Transmit x Receive):
      - 4x4 in 5.0GHz H
      - 4x4 in 5.0GHz L
      - 4x4 in 2.4GHz
    • OFDM/OFDMA: Both
    • BSS Coloring: Yes
    • Multi-User MIMO: Bidir and MU-MIMO
    • Target Wake Time: Yes
    • Maximum Theoretical Throughput: AX6000 6Gbps
    • Maximum Theoretical Throughput per Band:
      - 5.0Ghz H: 2400Mbps
      - 5.0GHz L: 2400Mbps
      - 2.4GHz: 1200Mbps
    • Antenna Gain: Internal 2.86/4.4.1/4.98 dBi (2.4GHz/5GHz L/5GHz H)
    • Power over Ethernet (PoE): 802.3bt/at
    • PoE Power Consumption: 30.1W
    • Centralized Management: Insight App
    • Secure Socket Layer (SSL): Yes
    • Router Mode: No

      Wireless Distribution System (WDS)
    • Repeater: Yes
    • Bridge Point-to-Point/Multi-Point: Yes
    • Simultaneous Bridge and Wireless Client Association: Yes
    • 802.1xRADIUS Support with EAP TLS, TTLS, PEAP: Yes
    • Neighbor AP Detection: Yes
    • Black SSID Broadcast: Yes
    • VLAN Support: Yes
    • Guest Netowrk/Captive Portal: Yes
    • Bandwidth Management: Yes
    • Link Layer Discover Protocol: Yes
    • Bandsteering: Yes
    • Wireless Backhaul to form Mesh Network: Yes

      Technical
    • IEEE 802.11ax WiFi 6 standard: Yes
    • WMM Wireless Multimedia Prioritization: Yes
    • WDS Wireless Distribution System: Yes
    • PoE IEEE 802.3af: No
    • PoE IEEE 802.3at: Yes, max throughput will reduce by 50% on 2.4Ghz and 5GH Low
    • PoE IEEE 802.3bt: Yes

      Physical
    • Dimensions (WxDxH): 10.49" x 2.18" x 10.56" (266.6mm x 55.5mm x 268.3mm)
    • Weight: 2.10lbs (956g)
    • Operating Temperature: 32°F - 104°F (0°C - 40°C)
    • Physical Interfaces: 1x 100/1000/2.5GBASE-T Gigabit Ethernet (RJ-45) ports with Auto Uplink™ (Auto MDI-X) supporting IEEE 802.3af, 802.3bt or 802.3at PoE
    • Power Adapter (not included): 12V3.5A
    • LED:
      - 1x Power and cloud connection
      - 2x LAN ports
      - 3x Radio (2.4GHz, 5GH H, 5GH L)

      Security
    • Wifi Protected Access® (WPA, WPA2, WPA3): Yes
    • WPA2 and WPA3 Enterprise: Yes
    • Wireless Access Control to Identify Authorized Wireless Network Devices: Yes
    • MAC Address Authentication: Yes

  • Item Includes:

    • 1x Netgear WAX630-100NA Insight Managed Wireless Access Point
    • 1x Wall/ceiling mount kit
    • 1x Installation guide

  • Warranty:

    • 5 Year Limited Warranty
