Gepco VPM2000 RG59 High Definition 4.5GHz SDI Coax Cable 500 Feet Black

    Gepco VPM2000 RG59 High Definition 4.5GHz SDI Coax Cable 500 Feet Black

    Manufacturer: Gepco

    Item #: VPM2000-500   •   MFG #: VMP2000-500


    This item is no longer available.
    Ask a Markertek Expert if you need assistance finding an appropriate substitute.



    Item unavailable. Please select another option.

    Items similar to the VPM2000-500

    California Residents:
    Cancer and Reproductive Harm -


    The Gepco Brand high-definition video coax series has been engineered to feature a 4.5 GHz bandwidth (for HDTV transmission), a gas-injected foam dielectric, lower attenuation, more RG types, excellent crush resistance, easy termination and a flexible jacket. The gas-injected dielectric and precision process control are critical factors in achieving superior electrical performance including faster velocity of propagation, tight impedance tolerance, low attenuation and low structural return loss across the entire 4.5 GHz bandwidth.

    Conductive elements consist of a stranded or precision-drawn solid copper center conductor and either a 92% or 95% braid with 100% foil shield for complete broadband shielding. The series contains a wide range of sizes to accommodate short-distance rack wiring or extended-distance point-to-point interconnect.

    • Features

      • Features:
      • Ultra-low Attenuation & Return Loss
      • Precision 75 Ohm Impedance
      • 4.5GHz Bandwidth for HDTV
      • High Velocity of Propagation
      • Gas-Injected Foam Dielectric
      • 100% Sweep Tested
      • Full Copper Braid & Foil Shield
    • Specifications

      • Specifications:
      • Conductor: 20 AWG Solid Bare Copper
      • RG Standard: RG59
      • Nominal O.D.: 0.242"
      • Insulation: Gas-inected Foam EP .146"
      • Shield: 95% TC Braid, 100% Foil
      • Jacket: PVC
      • UL Type: CMR
      • Return Loss (100kHz-1GHz) / (1GHz-4.5GHz): >23dB, >21dB
      • Capacitnce: 16.2 pF/ft
      • Weight/Mft.: 35 Lbs.
