ADJ MIR678 Mirage Par H IP Battery Powered DMX RGBAL+UV LED Par Light Fixture - IP65 Rated

ITEM #: AMDJ-MIR678 MFG #: MIR678

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$939.95

Our Price:

$679.99

Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup


MIR678 - Overview

The ADJ Lighting MIR678 Mirage Par H IP LED fixture is a versatile, high-performance lighting solution, perfect for events, installations, and stage productions. Equipped with five 20W Hex Color RGBAL+UV LEDs, it delivers a dynamic range of color, including lime and UV for unique lighting effects. With an adjustable white color temperature from 2,700K to 9,900K, the Mirage Par H IP allows access to massive gamut of colors.

This light can be powered via wall outlet or its rechargeable lithium-ion battery, providing user selected 5 to 20 hours of operation. Control options are expansive, including DMX512, Aria X2 wireless system for over the air firmware/software updates, Bluetooth, RDM and an IR remote. With a robust IP65-rated housing, it is weather-resistant, making it ideal for outdoor or indoor use.

Advanced features include variable refresh rates (900Hz to 25K), six dimming modes, four dimming curves, built-in programs, and electronic strobing and full dimming, giving users complete control over intensity and effects.

The Mirage Par H IP is both compact and rugged, ensuring easy setup, striking and transport. This versatile LED Par is designed for lighting professionals who need reliability, color versatility, adaptable power options and all-weather protection in one durable package.

  • Features:

    • 5 Pixel, Hex Color LED (RGBAL+UV) LED Par Battery or Wall Powered
    • Battery operation can be selected by the user for durations ranging from 5 to 20 hours
    • Built-In Programs
    • Variable White Color Temperature Control (2,700K ~ 9,900K)
    • User Selectable LED Refresh Rates (900Hz ~ 25K)
    • 6 User-Selectable Dim Modes
    • 4 User-Selectable Dim Curves
    • Electronic Strobe (0.3Hz ~ 11Hz)
    • Electronic Dimming

  • Specifications:

      Source
    • 5x 20W Hex Color RGBAL+UV LED's
    • 50,000 Hour Average Life

      Optical
    • 2,300K - 9,900K White Color Temperature Range
    • Beam Angle: 17°

      Physical
    • IP65 Housing
    • Digital display
    • Adjustable, hanging/kickstand bracket

      Control
    • DMX512
    • Aria X2 Wireless Management/DMX System
    • Bluetooth
    • RDM and RDM Net Compatible
    • IR (Includes UCIR24 wireless remote)
    • 6x DMX Channel Modes (5, 6, 9A, 9B, 15 & 17 Channel modes)
    • On-board Manual Control Mode
    • Primary/Secondary Mode

      Connections
    • Chogori IP65 data locking connectors
    • Chogori IP65 power connectors

      Dimensions & Weight
    • Length: 11.1" (282mm)
    • Width: 10.6" (269mm)
    • Height: 10.4" (265mm)
    • Weight: 11.9lbs (5.4kg)

      Power
    • AC 100V - 240V/50Hz-60Hz Input
    • 60W Power Consumption
    • Link 14 pieces @ 120V AC or 28 pieces @ 230V AC

      Battery
    • Rechargeable Lithium-ion
    • Battery Capacity: 6,600mAh
    • Battery Voltage: 22.2V
    • Charge Time: 5 Hours (To Full)
    • Battery operation can be selected by the user for durations ranging from 5 to 20 hours. 5 Hour duration will operate at Full Output when battery is fully charged
    • Battery Cycles: 500

      Thermal
    • Ambient Operational Temperature: -4°F - 104°F (-20°C - 40°C)
    • Storage Temperature: -22°F - 113°F (-30°C - 45°C)

      Certifications & IP Rating
    • CE
    • cETLus (#4002034)
    • FCC
    • IP65

  • Item Includes:

    • 1x MIR678 Mirage Par H IP Par Light Fixture
    • 1x WIF901-POWER CABLE (WIF901-POWER CABLE), IP65 Chogori to Edison Locking Power Cable
    • 1x CHS5INDMX (CHS366) - 20" Chogori locking output data connector to Seetronic 5-pin, IP65, male input XLR connector adapter cable. (Must be used with STRxxx, 5pin DMX cables to create IP65 seal)
    • 1x CHS5OUTDMX (CHS373) - 20" Chogori locking input data connector to Seetronic 5-pin, IP65, female output XLR connector adapter cable. (Must be used with STRxxx, 5pin DMX cables to create IP65 seal)
    • 1x Floor / Mounting Bracket
    • 1x UCIR24 Remote

  • Warranty:

    • 2 Year Warranty

  • GTIN:

    0810087373771
