Atomos SUMO 19 SE 4K HDR 19-Inch Monitor Recorder and Switcher


free ship

Our Price:


Availability: In Stock
iAvailability Description Popup

    SUMO 19 SE - Overview

    A Special Edition of Atomos 19 inch production monitor Sumo 19 SE that comes with an incredible panel P3 Quantum dot color, offering a better picture clarity. The Sumo SE is offering more for the same price as Sumo 19 and replaces Sumo 19 in their product portfolio.

    More than just a monitor the Sumo 19 is the perfect tool to bridge your 4K HDR workflow across multiple cameras, audio and Atomos devices. Sumo 19 is a Monitor-Record-Switcher, and highly adaptable to suit multiple applications.

    Unlock the true potential of your RAW cinema cameras with the Sumo 19. Preserve your sensor's pristine pixels in ProRes RAW at up to 5.7kp30, 4kp120 DCI/UHD and 2kp240 DCI/HD. CDNG supports up to 4kp30 DCI. Sumo 19 is compatible with Sony FS series, Canon C300MKII/C500 or Panasonic EVA-1/Varicam LT and more.

    Rugged and versatile design suitable for every application

    Live Quad-channel HD Switching & Recording:
    Take full advantage of 4 x SDI inputs and let Sumo 19 step into the role of a large-format quadview live switcher and recorder on your multi-camera shoots. Record up to four 1080p60 streams simultaneously as separate ISOs while cueing and switching in real-time with a simple touch of the screen. Sumo 19 allows user to record a fifth 'program' channel of your switched feed. Display the resulting mixed output (via HDMI or SDI) live on set. Switching is completely asynchronous, eliminating the need for expensive locked sources and allowing the use of more affordable cameras. You can easily output the switched feed for live streaming with a solution as simple as the Atomos Connect 4K.

    For professional productions large and small you save significant space - replacing several boxes in your rack, or decks and monitors on your desk with a single Sumo 19.

    HDR in the field and in the studio:
    HDR really comes to life on the Sumo 19. It's 19" 1920 x 1080 LCD panel with 10-bit processing takes the RAW/Log/PQ/HLG output from cameras or gaming consoles and precisely maps to display 10+ stops of dynamic range in real time. Use as a director or client monitor in the field, or an affordable HDR studio monitor.

    10-bit ProRes and DNx up to 4Kp60:
    Video from any camera or digital video source can be captured via SDI or HDMI. Record up to 10-bit 4:2:2 in ProRes or DNxHR codecs at 4Kp60 or 2Kp240, depending on the camera's capability. The depth and quality of the image is preserved with data rates of up to 1.8Gbs, 220MB/s.

    Two stereo balanced XLR inputs with 48V:
    Use full size XLR connections with 48V Phantom power to connect two external microphones with balanced analogue audio recording and monitoring. The Sumo19 has dedicated meters, gain controls and adjustments for frame delay on each channel. Mic or line level audio can be seamlessly synchronized with embedded audio from HDMI and SDI sources.

    • Features:

      • Live Quad-channel HD Switching & Recording
      • For professional productions large and small you save significant space - replacing several boxes in your rack, or decks and monitors on your desk with a single Sumo 19.
      • HDR in the field and in the studio
      • 10-bit ProRes and DNx up to 4Kp60
      • Two stereo balanced XLR inputs with 48V
      • 1200nit HDR: Touchscreen
      • ProRes RAW: Up to 6K
      • 4x ISO+Program: Record
      • Live Switch: Program Out
    • Specifications:

      • Weight:
        Without batteries, media & stand: 12.3Lbs
        With stand: 13.7Lbs
      • Dimensions (WxHxD):
        19.8 x 12.2 x 2.5" (without stand)
        19.8 x 13 x 7.1" (with stand)
      • Construction: Aluminum alloy chassis with built in armor protection
      • Mounting Points:
        1/4-20 screw; 4x top, 4x bottom, 2x side
        3/8-16 screw; 2x top, 2x bottom, 1x side
        VESA mount rear

      • Operating power: 75W
      • Compatible batteries: V-Lock / Anton Bauer via XLR terminal (optional mounting plates available)
      • Input Voltage (battery): 14.4V nominal
      • Battery Time (based on 7.4V): Depends on Watt Hours specification of battery used
      • DC In: 1 x DC in (6.2 - 16.8V) Continuous power
      • Patent Pending: Primary-secondary battery system.
      • Change Batteries without losing power - loop batteries continuously

      • Size: 19"
      • Resolution: 1920 x 1200
      • PPI: 120
      • Aspect Ratio: 16:9 native
      • Color Gamut: REC709 HDTV
      • Look up Table (LUT) Support: 3D LUT (.cube format)
      • Anamorphic De-Squeeze: 2x, 1.5x, 1.33x, Panasonic 8:3
      • Technology: SuperAtom IPS panel (capacitive touch), calibration to Rec.709 with optional calibration unit

      • AtomHDR: Yes
      • Supported Log formats: Sony SLog2 / SLog3, Canon CLog / CLog 2, Arri Log C, Panasonic Vlog, JVC JLog, Red LogFilm
      • Supported Gamuts: Sony SGamut / SGamut3 / SGamut3.cine, Canon Cinema / BT2020 / DCI P3 / DCI P3+, Panasonic V Gamut, Arri Alexa Wide Gamut
      • Bit depth: 10-bit (8+2 FRC)
      • Brightness: 1200nit (± 10%)
      • HDR Input/Output (PQ/HLG): Yes / Yes

        Video Input/Loop Out
      • HDMI: 1x HDMI (2.0)
      • SDI: Quad link 4x 3G SDI* or up to 12G single link SDI
      • Signal: Uncompressed true 10-bit or 8-bit 422 (camera dependent)

        Video Output (Play Out)
      • HDMI: 1 x HDMI (2.0)
      • SDI: 1x 4K-SDI 12G/6G or HD-SDI 3G/1.5G
      • Signal: Uncompressed true 10-bit or 8-bit 422 (playback file dependent)
      • Supported Loop Out Formats
      • HDMI to HDMI: 720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60/100/120, 2160p 24/25/30/50/60
      • SDI to SDI: 720p 50/60, 1080i 50/60, 1080pSF 24/25/30, 1080p 24/25/30/50/60/100/120, 2160p 24/25/30/50/60

        Video Signal Conversion
      • HDMI to SDI: 720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60/100/120/200*/240* 2160p 24/25/30/50/60
      • SDI to HDMI: 720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60/100/120/200*/240* 2160p 24/25/30/50/60

        Onboard Processing
      • Pulldown Removal: 24/25/30pSF > 24/25/30p (2:2 pulldown) 60i > 24p (3:2 pulldown)
      • 4K UHD Downscale for HD monitoring: Yes - Loop-out and playback (Not available in RAW)

        Audio In/Out (48kHz PCM Audio)
      • HDMI: 2 or 8ch 24-bit, camera dependent
      • SDI: 12ch 48kHz 24-bit
      • Audio: 2ch balanced XLR analog in/out (direct XLR connection)
      • Dynamic Range: >90dB
      • Max Signal Level: +24dBu
      • Max Analog gain: +52dB
      • Phantom Power for Mic: 48V
      • Headphone Out: 3.5mm
      • Built-in Speakers: Yes
    • Item Includes:

      • 1x Sumo unit
      • 1x Master Caddy II
      • 1x BattWing mounting bracket with 4x screws
      • 2x Desktop Feet with 4x 1/4" Mounting screws
      • 1x AC power supply
    • Warranty:

      • Warranty 1 year Extended to 3 years on product registration
    • GTIN:
