Belkin F4U109TT Thunderbolt 3 Dock Plus for Mac & PC

ITEM #: BKN-F4U109TT MFG #: F4U109TT

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:


Our Price:


Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup

    F4U109TT - Overview

    The Instant Workstation
    Fast, ultra-high definition, powerful, and now even more versatile, meet the new wave of Thunderbolt 3 Docks. The Belkin F4U109TT Thunderbolt 3 Dock Plus offers universal compatibility, bringing all the benefits and convenience of Thunderbolt 3 technology to both Mac and Windows laptops. With 40Gbps transfer rates,* 60W power to charge your connected laptop, dual 4K 60Hz monitor support and multiple ports for peripherals, simply connect the dock to your Mac or Windows laptop - with the included Thunderbolt 3 cable - to create a high-performing, instant workstation.

    The Belkin Difference:

  • Pioneer in innovation and technology for over 35 years
  • Designed with professional and at-home users in mind
  • Building on the success of their CES 2018 Best of Innovation Awards Honoree, the Thunderbolt 3 Express Dock HD
  • Insertion testing guarantees quality for lasting performance and durability
  • Tested under fluctuating environmental conditions to ensure safety of materials
  • More Ports For More Devices
    Connect all your peripheral devices - monitors, mice, keyboards, speakers, hard drives and more - to your laptop via a single cable.

    Thunderbolt 3 Type-C port with PD 3.0 delivers charging (up to 60W) to laptop with the included Thunderbolt 3 Gen 2 cable
    Audio in/out for mic and speaker support
    1 x USB-A 3.1 Gen 2 port for USB-A peripherals

    Gigabit Ethernet connection
    2 x USB-A 3.1 Gen 1 ports for devices that connect via USB-A such as a mouse, keyboard or printer
    2 x USB-C 3.1 Gen 2 ports for USB-C peripherals
    2 x DisplayPort™ 1.4 connect to high-resolution monitors/displays (for resolutions, see table below)
    125W PSU (Power Supply Unit) powers the dock, and also charges the connected laptop up to 60W, to keep your laptop charged as you work

    Thunderbolt 3 And USB-C Compatible
    Thanks to the inclusion of a smart chipset/controller from Intel, this dock supports both Thunderbolt 3 and USB-C, and is also fully compatible with both MacBooks running Mac OS, and laptops running Windows. Such broad compatibility makes it the ideal choice for temporary workstations or shared work environments, which are visited by different users, who may have different laptop types but still need an easily accessible and high-performing workstation. The Thunderbolt 3 Dock Plus is also a convenient, economical, single dock solution for businesses supporting both Mac and Windows laptops within their organization.

    Dual High-Definition Monitor Support
    With so many ports available, the Thunderbolt 3 Dock Plus easily connects two high-definition displays, without compromising access to your other peripherals. Please see the table below for specific resolution capabilities for all monitor combinations.

    Single Monitor Support:
    Thunderbolt 3 Laptop:
    Laptop running High Bit Rate 3: 8K (7680 x 4320) @ 30Hz
    Laptop running High Bit Rate 2: 4K (3840 x 2160) @ 60Hz
    USB-C Laptop:
    Laptop running High Bit Rate 3: 5K (5120 x 3200) @ 30Hz
    Laptop running High Bit Rate 2: 4K (3840 x 2160) @ 30Hz
    *USB-C host performance will be limited. Note that not all USB-C ports support the full functionality of the USB Type-C standard. USB-C hosts may not support extended display to external monitors.

    Power To Share
    With its power supply unit drawing 125W from the mains, the Thunderbolt 3 Dock Plus is able to provide up to 60W of power for a connected laptop. Also known as "upstream charging," this keeps your laptop charged while in use, without the need for a separate power cable.

    • Features:

      • Plastic body
      • Supports dual monitors of 4K at 60 Hz
      • Supports single display of 8K at 30 Hz
      • Up to 60W charging using the front Thunderbolt 3 port
      • Stereo headphone / microphone input jack
      • Two USB-C ports
      • Three USB-A ports
      • Gigabit ethernet port
      • Security K-Lock
      • 2.6 ft / 0.8 m Thunderbolt 3 cable
      • One SuperSpeed USB-A 3.1 Gen 2 port
      • One Thunderbolt 3 port supporting Power Delivery up to 60W
      • One TRRS Audio In/Out jack for a mic and headset
      • One Gigabit ethernet port
      • Two SuperSpeed USB-A 3.1 Gen 1 ports
      • Two USB-C 3.1 Gen 2 ports
      • Two DisplayPort 1.4 monitor outputs
      • Power jack
      • Security K-Lock
    • Specifications:

      • Compatibility
      • Windows 10
      • macOS® 10.12 Sierra

        Power Supply
      • Input: 100-240VAC / 1.8A / 50-60 Hz
      • Output: 20V / 6.75A / 135W
      • Center Pin Positive
      • Uses IEC 320 C5 power cable

        Weights & Dimensions
      • W: 165.7mm / 6.52 in
      • D: 77.6mm / 3.06 in
      • H: 31mm / 1.22 in
      • Weight: 267g / 9.42 oz
    • Item Includes:

      • 1x Belkin F4U109TT Thunderbolt 3 Dock Plus for Mac & PC
      • 1x AC power adapter
      • 1x 0.5m / 1.6ft Thunderbolt 3 cable
    • GTIN:
