Blustream SC12SP-V2 HDMI 18G Splitter/Down-Scaler w/Audio De-Embed

ITEM #: BLU-SC12SP-V2 MFG #: SC12SP-V2

  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
free ship

Our Price:

$416.00

Availability: In Stock
iAvailability Description Popup


    SC12SP-V2 - Overview

    The Blustream SC12SP-V2 is a 4K HDMI 2.0 splitter with in-built scaler, designed for installations in which a single 4K video source needs to be distributed to multiple displays that support different maximum video resolutions. The SC12SP-V2 supports downscaling of up to 4K @ 60Hz 4:4:4 video to various lower resolution video formats. The SC12SP-V2 also includes audio breakout, advanced EDID management and supports HDCP2.2

    • Features:

      • Features 1 x HDMI input that is replicated to 2 x HDMI outputs
      • Supports HDMI 2.0 18 Gbps specification including HDR
      • Supports up to 4K UHD 60Hz 4:4:4
      • HDMI output 2 supports 4K UHD video pass-through
      • HDMI output 1 will down-scale the video input to the following formats:
      • - [email protected] 24/25/30/50/60Hz (for screens that do not support 4K)
      • - 4K 50/60Hz 4:2:0 (for screens that do not support full 4K @ 60Hz 4:4:4)
      • Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD
      • Master Audio transmission
      • HDMI audio breakout to analog L/R audio and coaxial digital outputs concurrently
      • Advanced EDID management
      • HDCP2.2 support

    • Specifications:

      • Video Input Connectors: 1 x HDMI Type A, 19-pin, female
      • Video Output Connectors: 2 x HDMI Type A, 19-pin, female
      • Audio Output Connectors: 1 x RCA (S/PDIF), 1 x 3.5mm stereo jack (L/R)
      • EDID: 4-PIN DIP switch
      • Product upgrade: 1 x 3-Pin Phoenix connector & 1 x Type A USB female
      • Dimensions (W x H x D): 122mm x 23mm x 135mm
      • Shipping Weight: 0.8kg
      • Operating Temperature: 32°F to 104°F (0°C to 40°C)
      • Storage Temperature: -4°F to 140°F (-20°C to 60°C)
      • Power Supply: 5V/1A DC

    • Item Includes:

      • 1x SC12SP-V2
      • 1x 5V/1A DC power supply
      • 1x Mounting kit
      • 1x Quick Reference Guide

    • Warranty:

      • 3 Year Warranty

    • GTIN:

      9340242002266
