DUAL-7-RM-LCD Dual 7-Inch RackMount Video Monitor with Loop Through

ITEM #: DUAL-7-RM-LCD MFG #: RACK-LCD-7-2

  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
free ship

List Price:

$249.95

Our Price:

$229.95

Availability: In Stock
iAvailability Description Popup


    RACK-LCD-7-2 - Overview

    A cost effective dual 7" screen rackmount video monitor for composite video applications where a good no-frills quality is required.

    Housed in a very lightweight anodized aluminum 19" rack mount enclosure - perfect for customers who need to monitor Composite video for a low cost. Although not intended for 24/7 operation, many find that this unit is quite functional when the budget trumps the need for higher cost feature rich models. It operates at 12VOLTS @ 1.2Amps and features front and rear BNC video inputs that both have a LOOP OUTPUT in the rear.

    The DUAL-7-RM-LCD can be powered by any 12VOLT DC source including batteries or 12VOLT power rails. The power supply is 110/220V 50/60 CYC and will work in 220V countries with the proper plug adapter (not included).Unit is 16X9 aspect ratio only and displays 16X9 video, when 4X3 video is input it is stretched to fit the 16X9 display

    Please Note: Power Supply is Not Included.

    • Features:

      • Dual monitor LCD 19" rackmount
      • Each monitor has two BNC inputs (front and rear)
      • Rear loop-out BNC female port
      • Toggle switch for video input
      • OSD menu for video adjustments
      • Front On/Off buttons
      • 800 x 480 (16:9) LCD panel resolution (NTSC standard is 525 lines interlaced). See sample below for real-life image.
      • 19" wide, 5.25" tall, 3.3" deep
      • Recommended power adapter (12V DC, 1000mA)

    • Specifications:

      • Power Input 12V DC 1A
      • Operating Temperature 0°C to 40°C
      • Operating Altitude 10,000ft
      • Storage Temperature -20°C to 85°C
      • Storage Humidity 10% to 95% RH
      • Storage Altitude 50,000ft
      • Vibration 10-500Hz
      • Reliability100K Hours at Max Load
      • Input Connector BNC Female
      • Screen Size 7 inches
      • Display Resolution (Pixels) 800 (H) x 480 (V)
      • Active Area (mm) 52.40 (H) x 91.44 (V)
      • Pixel Size (um) 190.5 x 190.5
      • Display Colors Full Colors
      • Restrictions:
      • This product is not authorized for use in life supporting systems, aircraft navigation control systems, military systems and any other application where performance failure could be life-threatening or otherwise catastrophic
      • FCC Verified

    • Warranty:

      • 30 DAY warranty
