Hall Technologies EX-HDU-WP HDMI and USB Extension on CAT6 Decora Wall Plate Sender

ITEM #: HRT-EX-HDU-WP MFG #: EX-HDU-WP

  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

800-522-2025Email

Items similar to the HRT-EX-HDU-WP

EX-HDU-WP - Overview

The EX-HDU-WP is used to extend HDMI video and USB data on a single Cat6 cable up to 200 ft (60 meters). HDMI audio is extracted and is provided on the rear of the wall plate as SPDIF digital (Audio is also available on compatible receiver as analog stereo). The EX-HDU-WP is designed to work with EX-HDU-R (or EX-HDU-R-IP) receiver. The EX-HDU-WP extender connects to the receiver using standard CAT5e/6 UTP cabling up to 200 feet (60 Meters) long. The wall-plate Sender gets its power from the Receiver via the same UTP cable and does not need a separate power supply. For convenience, the patent pending wall plate features a USB hub with two USB ports for connection of USB devices. The plug-and-play extender is compatible with all PCs, MACs, and Android Tablets and does not require driver installation. Simply plug the PC's HDMI and USB ports to the sender.

  • Features:

    • Extends HDMI + USB 2.0 to 200 ft (60 m) on one Cat 6 cable
    • Wall plate sender has 2-port hub for connection to USB devices to the host PC
    • Perfect for Interactive displays, Soft CODECs, and KVM extension
    • Wall plate does not require separate power supply
    • Compact, Rugged, Reliable and Economical

  • Specifications:

    • Video Standards: DVI (Single Link) HDMI 1.4 HDCP 1.1
    • Signal Type: TMDS
    • Connectors: EX-HDU-WP (1) HDMI Input
    • Resolutions: DVI - VGA (640x480) thru WUXGA (1920x1200) HDTV - 480p thru 1080p60 (no interlaced support)
    • Audio Format: LPCM 2 Channel Audio (32-192kHz sample rate)
    • Power Supply: 100 to 240 VAC, 47-63 Hz, External; 12VDC
    • Storage Temperature/Humidity: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, non-condensing
    • Operating Temperature/Humidity: +32 to +122 °F (0 to +50 °C) / 10% to 90%, non-condensing
    • Cooling: Convection
    • Enclosure: Metal (Steel)
    • Dimensions: 2.60" H x 1.30" W x 1.80" D
    • Weight Model Only: 0.75 lb
    • Shipping: 1.25 lb
    • Vibration: ISTA 1A in carton (International Safe Transit Association)
    • Safety: CE EMI/EMC:CE, FCC Class A
    • MTBF: 90,000 hours (Calculated Estimate)
    • Warranty: 3 years parts and labor

  • GTIN:

    0724696530688
