Juice Goose RT-REL AC Current Dry Contact Relay Trigger

ITEM #: JG-RT-REL MFG #: RT-REL

Primary Image
Free Shipping with $49 Minimum Order

List Price:

$62.00

Our Price:

$56.00

Availability: In Stock
iAvailability Description Popup


    RT-REL - Overview

    Plug the power cord of the Juice Goose RT-REL into a switched AC outlet. In its unpowered state, there is an internal contact between the C (common) and NC (normally closed) terminals on the unit. When 120VAC power is applied to the power cord, connection is opened between C and NC and closed between C and NO (normally open).

    The RT-REL can be used with any product that needs a contact closure to activate, including the Juice Goose SQ-1500.

    A common application for the RT-REL is to extend the use of a switched electrical outlet on a rack mounted power strip or sequencer or on some other device such as an audio receiver or amplifier. When plugged into the switched outlet the RT-REL can close and open a dry contact on the three position terminal strip.

    Made in America

    • Specifications:

      • Chassis: Durable Plastic (Black)
      • Dimensions (Inches): 3 x 2 x 1
      • Weight (Ounces): 48
      • Power Cable: 3 Feet, 18/2 AWG with NEMA 5-15P
      • Relay Contact Rating (Amps): 10
