Kramer PT-2C 4K Extended EDID Processor
  • Kramer PT-2C 4K Extended EDID Processor
  • Kramer PT-2C 4K Extended EDID Processor

Questions? Ask a Markertek Expert:
800-522-2025 Email

Kramer PT-2C 4K Extended EDID Processor

Manufacturer: Kramer

Item #: KR-PT-2C   •   MFG #: PT-2C



List Price:$297.00
Our Price:$237.60

free ship


Availability: Direct Ship From Manufacturer
i
Item ships directly from the manufacturer and is subject to manufacturer availability. We will contact you with expected availability. You can also email [email protected], chat or call customer service (800)-522-2025 for expedited delivery options.




    Share!

    California Residents:
    8pt-triangleWARNING:
    Cancer and Reproductive Harm - www.P65Warnings.ca.gov





    The PT-2C is an EDID processor for 4K HDMI signals. It allows you to pass or block HDCP, multi-channel audio or deep color signals that may or may not be compatible with the display. This product, which incorporates HDMI technology is ideal for: Legacy infrastructures that require advanced feature support; troubleshooting aid for installers on legacy infrastructures; education, entertainment, corporate and government applications. Extended Display Identification Data (EDID) is a data structure provided by a digital display to describe its capabilities to a video source (e.g. graphics card or set-top box). It is what enables a modern personal computer to know what kinds of monitors are connected to it.


    • Features

      • 4K resolution support
      • HDMI line-powered - No power supply needed
      • Active video signal source detection
      • Mount 4 units side–by–side in a 1U rack space with the optional RK–4PT rack adapter
      • Audio-E
      • 4K Resolution Support
      • Maximum Data Rate: 10.2Gbps (3.4Gbps per data channel)
      • HDMI and HDCP Compliance
      • Signal Reclocking
      • Active Video Signal Source Detection
      • Configurable Timeout - For when the input signal is lost

    • Specifications

      • Input: 1 HDMI connector
      • Output: 1 HDMI connector
      • Ports: 1 mini USB
      • Max Data Rate: 10.2Gbps (3.4Gbps per data channel)
      • Standards Supported: Supports HDMI and HDCP
      • Controls: 8 DIPswitches
      • Standards: HDMI with Deep Color, x.v.Color and 3D; HDCP - works with sources that support HDCP repeater mode
      • Indicator LEDS: HDMI In, HDMI Out, Power
      • POWER REQUIREMENTS: 5V DC, 350mA
      • Operating Temperature: 0° to +40°C (32° to 104°F)
      • Product Dimensions: 6.22cm x 5.18cm x 2.44cm (2.45" x 2.04" x 0.96" ) W, D, H
      • Product Weight: 0.7kg (1.5lbs) approx
      • Shipping Dimensions: 15.70cm x 12.00cm x 8.70cm (6.18" x 4.72" x 3.43" ) W, D, H
      • Shipping Weight: 0.4kg (0.9lbs) approx
      • Storage Temperature: –40° to +70°C (–40° to 158°F)
      • Humidity: 10% to 90%, RHL noncondensing
      • Cooling: Convection
      • Enclosure Type: Aluminium
      • Rack Mount: With optional adapter
      • Furniture Mount: With included rubber feet
      • Vibration: ISTA 1A in carton (International Safe Transit Association)
      • Compliance Standards: CE
      • Environmental Regulatory Compliance: Complies with appropriate requirements of RoHs and WEEE

    • Item Includes

      • PT-2C Extended EDID Processor
      • 4 Rubber Feet
      • 1 Quick Start Guide
