Ross Carbonite Black Solo 13 Input 6 Output - All In One - 1 M/E Production Switcher

ITEM #: ROSS-CBSOLO-13 MFG #: CBSOLO-13

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
Free Shipping with $49 Minimum Order

List Price:

$8,085.00

Our Price:

$7,350.00

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    CBSOLO-13 - Overview

    The Super Compact Switcher
    Carbonite Black Solo 13 is a powerful "All-In-One" 1ME switcher that is packed full of the features that Carbonite owners love to use every day. Compact and affordable, this switcher is built with a professional- class feature set to ensure a captivating and easy-to-execute show.

    Unlike other small production switchers, Carbonite Black Solo offers: MiniME Resources for Event Production or Secondary Outputs: Carbonite Black Solo comes equipped with 2 MiniMEs, each of which has two keyers of its own. Freely assignable throughout the channel stream, MiniMEs are great for multi-layer effects, unique outputs or multi-screen processors for a live event.

    One Button Playout of Complex Scenes With Robust Macros and Memories Complex scenes and ultra-fluid transition effects require a smart macro and memory system, but many small switchers lack this functionality. Carbonite Black Solo provides finely-tuned custom control macros, plus a large memory system with smart key/background preparation and smooth effect recall functionality. Built-in Monitoring and Video Processing to Eliminate Additional Purchases What good is a portable production switcher, if you need a pile of external equipment to get the connections right? Carbonite Black Solo lets you quickly plug-in to any facility with built-in frame syncs, format converters, and a 10-window MultiViewer.

    • Features:

      • Whether looking to equip a production studio, flight pack, or add a back-up switcher - Solo is designed to empower your operators and simplify the production workflow
      • Spectacular ME resources for production flexibility
      • Includes great-looking graphics software
      • Eliminates monitoring and video processing costs
      • Increases productivity with smart show tools and widespread connectivity

    • Specifications:

      • Inputs: 12x 3G HD-SDI / 1x HDMI
      • Outputs: 5x 3G HD-SDI / 1x HDMI
      • Standard Definition: 480i/59.94 - 4:3 and 16:9 | 576i/50 - 4:3 and 16:9
      • High Definition: 720p 50/59.94, 1080i 50/59.94 | 1080pSF, 23.98/25/29.97 | 1080p 25/29.97
      • 3G 1080p: 1080p 50/59.94
      • Chroma Key: 1 UltraChrome chroma keyer
      • DVES: 2 (2D) floating DVES can be utilized in any keyer in the system
      • Stills & Animations: 4 Channels of MediaStore with a total storage capacity of 8GB. Each channel can render stills/animations or two channels can be paired together for animations with alpha. Supports animations with audio or audio-only playback. Each channel can be converted for use as a frame synchronizer.
      • Graphics Software: Included XPression LiveCG software creates still graphics from network connected-PC workstation and renders directly into MediaStores via Ethernet
      • Supported Media File Types: Stills: .BMP Stills & Animations: .JPG, .JPEG (no Alpha), TGA & PNG (with Alpha & 48K WAV audio files)
      • Pattern Generators: 2 Pattern Generators
      • Effects & Transitions: Support for standard transitions along with Animated MediaWipes with audio and overlay effects on main ME. Dissolve transitions are available to MiniMEs.
      • Memories: 100 Memories per ME and MiniME per Show File. Multiple show files can be stored on the USB drive. Effects Memory functionality allows for animated memory recalls, while MemoryAI ensures memory recalls will not affect what is currently on-air.
      • Custom Control Macros: 72 Custom Control Macros are available for use directly from the control panel, while up to 256 Custom Controls can be created in DashBoard
      • Internal Frame Synchronizers & Format Converters: 6 freely-assignable Frame Syncs & Format Converters. If the switcher is operating in 1080p 59.94, you can only use a maximum of 7 frame synchronizers to sync 1080p 59.94 video inputs. This can be up to 3 FSFCs and 4 MSFSs or 6 FSFCs and 1 MSFS. Format conversion is not restricted.
      • Monitoring: 1 MultiViewer with tally, source names, and clock. Configurable with up to 10 windows.
      • Control Interfaces: Control from any Carbonite Panel - up to 3 physical panels! DashBoard VirtualPanel and additional DashBoard Custom Panels.
      • Device Control: Includes device control for Servers, XPression Graphics, Robotics, Audio Mixers, PBus, GPO, Trackless Virtual Sets and PTZ Cameras
      • IP, Serial And Parallel Tally: 16 Tallies
      • GPI/O: 24 GPI/O Connections
      • AES Digital Audio: 1 AES Digital Audio Output
      • Time Code Input: Via Optional Gear Lite LTC to RS422 Converter (TSC-9902)
      • Ethernet Ports: 1 Ethernet Port
      • Reference Input: Black or Tri-Level
      • Editor/Serial Tally Port: 1 (RS-422)
      • Edit Decision Lists: LiveEDL can capture EDL data in a file that you load into your non-linear editing (NLE) suites
      • System Physical: 1RU Rack Frame, with support for redundant power supplies.
