SARETRACK - Overview

Durable and versatile reamp box

The Samson SARETRACK ReTrack is a compact and convenient reamplification box designed for the everyday musician. As part of the durable S-Max line, the ReTrack provides studio-grade signal quality to run a clean recorded track to an external amplifier in order to record new tones from the same audio source.

Versatile By Design
The ReTrack is designed to easily integrate into any studio setup. The main input is an XLR/TRS combo input, accommodating either type of connection from mixers or USB audio converters. ReTrack also features an input selector that allows it to be fed from either a standard line output or a stereo headphone output. This avoids unplugging the speakers on smaller interfaces to use it.

Ready For The Studio
ReTrack is designed to give you the best sound possible when re-amping for your studio sessions. The main output is an instrument-level 1/4" output that will work with any type of external amplifier or effects unit. ReTrack also features a rotary volume control for adjusting the headroom on your amplifier, and a ground lift switch to eliminate hum from other electronics.

S-Max Durability
As part of Samson's S-Max line of signal boxes, ReTrack is housed inside a 14-gauge steel chassis able to handle the stresses of both in-house studio work or on-the-go engineering. The all-metal enclosure keeps ReTrack's internal components and switches safe and protected for all its endeavors.

  • Features:

    • Durable, all-metal enclosure
    • XLR/TRS combo input
    • 1/4" instrument output
    • Rotary volume control
    • Headphone source selector switch
    • Ground lifts on both input and output

  • Specifications:

    • Type: Passive Reamplification Box
    • Frequency Response: 20Hz - 20kHz ±0.5dB
    • Input Impedance: Line 7.5kΩ, Headphones (Stereo Input) 1.9kΩ
    • Output Impedance: 10kΩ to 22.5kΩ, Varies with LEVEL TO AMP Position
    • Load Impedance: Typical Guitar Amp 1MΩ & 10' Cable
    • Gain: +8dB, 0dB With LEVEL TO AMP at Mid Position
    • Max Input Level: +18dBu @ 20 Hz 1% THD+N Max, +20dBu 24Hz - 20kHz
    • Transformer: Samson Custom Designed Passive Isolation
    • Controls: "LEVEL TO AMP" Rotary Volume Control, Mute Switch, Ground/Lift Switch, Headphone/Line Input Switch
    • Connectors: XLR-1/4" TRS Combo Input, 1/4" TS Output
    • Construction: 14-gauge steel chassis
    • Dimensions (LxWxH): 5.5" x 4.25" x 2.5" (139.7mm x 108mm x 63.5mm)
    • Weight: 1.6lbs (0.7kg)

  • Item Includes:

    • 1x SARETRACK Reamp Box

  • Warranty:

    • 2 Year Limited Warranty
