    16-1801 - Overview

    The SmallHD Cine 18 offers a perfect blend of screen size, brightness, color-accuracy, and portability, making it the most flexible High-Bright 4K Monitor for any production scenario. It's big enough for Video Village, bright enough for daylight viewing, and its ultra-lightweight aluminum unibody construction is the result of years of real-world, on-set testing. Features include 1100nits brightness, exceptional image quality, 1000:1 contrast ratio, and 4x 12G-SDI Inputs/Outputs for workflows up to 4K resolution. Ideal for Video Village, ACs, DPs, DITs, or as a director's monitor.

    • Specifications:

      • Display
      • Diagonal Size: 18.4
      • Resolution: 3840x2160
      • Brightness: 1100nits
      • Contrast: 1300:1
      • Gamut: 100% REC.709
      • Color Depth: 10-bit (8+2)
      • Backlight Type: Edgelit
      • Display Size: 18"
      • Panel Resolution: 3840 x 2160
      • Color Bit Depth: 10-bit (8+2)

        Input Signal
      • 12G-SDI Input Types: 4x 12G-SDI
      • HDMI Input Types: 1x HDMI 2.0 (4K60)

        Output Signal
      • 12G-SDI Output Types: 4x 12G-SDI
      • HDMI Output Types: Coming Soon
      • Audio Output Types: 3.5mm 3-pin Stereo Headphone Jack (coming soon)

        Power
      • Input: 1x XLR 4-pin 12 - 34VDC IN (210W max, 12V-34V, 18A max)
      • Output:
        2x 2pin (12V / 2A combined)
        1x USB (2.4A) (Front)
        1x USB (1.5A) (Front)
        1x USB-C (5V / 1.5A)
      • Battery Plate Included: No
      • Battery Types: 1x Dual-GM/VM Batt.Plate (14/26V) (sold as accessory)

        Data I/O Connector Type:
        1x SD Card Slot
        1x RJ45 Ethernet
        1x RJ45 GPI

      • Weight: 11.15lbs (5.06kg)

    • Item Includes:

      • 1x Cine 18 4K High-Bright Monitor
      • 1x 3ft HDMI cable
      • 1x 24V Power Supply
      • 1x Cleaning cloth

    • GTIN:

      0811786033201
