TRENDnet TEG-MGBS10D5 Mini-GBIC Version v4.0R Dual Wavelength Single-Mode LC Receiver Module - 1.25Gbps - 1550 - 10km

ITEM #: TEG-MGBS10D5 MFG #: TEG-MGBS10D5

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

List Price:

$49.99

Our Price:

$46.99

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


TEG-MGBS10D5 - Overview

The TRENDnet hot-pluggable TEG-MGBS10D5 must be paired with the TEG-MGBS10D3 or other compatible module. This SFP Dual Wavelength Single Mode LC Type module spans distances of up to 10 kilometers (6.2 miles). The SFP interface is compatible with standard SFP slots and supports a 1000 Mbps-LX interface.

  • Features:

    • Must pair with TEG-MGBS10D3 or other compatible module
    • Compliant with IEEE 802.3z Gigabit Ethernet
    • ANSI Fiber Channel compliant
    • Compliant with Small Form-Factor Pluggable (SFP) Multi-Source Agreement (MSA) ports
    • Supports data rate of up to 1.25 Gbps
    • Transmission distance of up to 10 km (6.2 miles)
    • Metal Enclosure with low Electromagnetic Interference (EMI) design
    • Simplex LC optical interface
    • Hot pluggable
    • Low power consumption
    • Lifetime Warranty*

  • Specifications:

    • Standards
    • IEEE 802.3z Gigabit Ethernet
    • ANSI Fiber Channel compliant
    • Class 1 Laser

      Interface
    • SFP MSA Compliant
    • Simplex LC optical interface

    • Power Consumption: Max. 0.8 Watts
    • Dimension: 57 x 13 x 12 mm (2.2 x 0.5 x 0.5 in.)
    • Weight: 18g (0.6 oz.)

      Temperature
    • Operating: 0°C ~ 70°C (32°F ~ 158°F)
    • Storage: -40°C ~ 85°C (-40°F ~ 185°F)
    • Humidity: Max. 85% (non-condensing)

    • Certifications: CE, FCC

      Wavelength
    • TX: 1550 nm
    • RX: 1310 nm

    • Optical Output Power (dBm): -9 ~ -3
    • Optical Input Power (dBm): -23 ~ -3
    • Power Budget: -14
    • Distance: 10 km

  • Item Includes:

    • 1x TEG-MGBS10D5
    • 1x Quick Installation Guide

  • GTIN:

    0710931610284
