Vaddio AV Bridge Nano Portable Desktop Audio and Video Encoder with Conferencing - HDMI to Plug-and-Play USB 3.0

ITEM #: VAD-999-82600000 MFG #: 999-82600-000

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:


Our Price:


Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup

    999-82600-000 - Overview

    Building upon the success of the AV Bridge Mini and AV Bridge 2x1, the Vaddio AV Bridge Nano is a brand-new addition to the product family known for its ability to connect professional AV equipment to USB and IP streaming applications. It retains some of the most popular qualities of the full-featured AV Bridge models in a highly portable, cost-effective device that IT and enterprise users will appreciate. The AV Bridge Nano also complements AV systems in lecture halls, town hall meetings, or houses of worship.

    The AV Bridge Nano enables reliable streaming and video capture scenarios over USB or RTSP/RTMP without needing to purchase two separate devices. The essential feature set makes it ideal for the corporate user in cost-conscious applications that do not require the full functionality of the AV Bridge Mini. It is fully compatible with the Vaddio Deployment Tool and Vaddio Device Controller touchscreen accessory, and the HDMI pass-through feature makes it easy to integrate into Cisco codec setups.

    The AV Bridge Nano is compatible with the most popular soft conferencing applications, such as Microsoft Teams, Zoom, WebEx and others, thanks to its powerful USB 3.0 interface. It can also be used as a USB capture card for ingesting HDMI video into video editing applications like Adobe Premiere and OBS Studio. Its networking capabilities enable the creation of production-quality live streams on platforms such as YouTube Live, LinkedIn, Facebook, Twitch, Dacast and Panopto.

    The smallest chassis in the Vaddio AV Bridge lineup ensures ultimate portability and allows the AV Bridge Nano to be mounted under a table, behind a display, or within a mobile conferencing cart system with the optional table-mount. The Kensington lock port provides peace of mind.

    • Features:

      • Bridge any HDMI video and audio source into soft conferencing applications
      • Reliable streaming and video capture scenarios over USB or RTSP/RTMP
      • Select USB 3.0 or IP Streaming (configurable as RTSP or RTMP)
      • IP streaming resolution up to 1080p/30 and USB streaming resolution up to 1080p/60
      • HDMI pass-through for ease of integration with Cisco codecs
      • Stereo unbalanced line in and line out
      • Kensington Security Slot for peace of mind
    • Specifications:

      • Dimensions (WxHxD): 5.8 in x 1.3 in x 4.4 in (14.8 cm x 3.2 cm x 11.3 cm)
      • Weight: 1.6 lbs (0.7kg)
      • Browser-based User Interface for Remote Control: Built-in
      • Color: Black
      • Top Resolution: 1080p 60FPS
      • OneLINK Compatibility: No
      • Power Type: Local Power
      • Control Method:
        - Telnet
        - Web UI
      • Input Ports:
      • - 3.5mm stereo Line Level Audio
        - HDMI
        - RJ-45
      • Output Ports:
        - Audio Line Out
        - HDMI
        - IP Streaming
        - USB 3.0 Type C (uncompressed USB 3.0, MJPEG compression on USB 2.0)
      • Power Supply:
        - 1.5A
        - 12VDC
    • Item Includes:

      • 1x AV Bridge Nano
      • 1x 12V power supply with international adapter plugs
      • 1x 3 ft. (0.9m) USB 3.0 cable, type C to A
      • 1x Quick-start card
    • Warranty:

      • 3-Year Warranty
