Gra-Vue MIO-DEC-AUD Analog Video & Dual Analog Audio to SDI Converter
  • Gra-Vue MIO-DEC-AUD Analog Video & Dual Analog Audio to SDI Converter
  • Gra-Vue MIO-DEC-AUD Analog Video & Dual Analog Audio to SDI Converter
  • Gra-Vue MIO-DEC-AUD Analog Video & Dual Analog Audio to SDI Converter
  • Gra-Vue MIO-DEC-AUD Analog Video & Dual Analog Audio to SDI Converter

Questions? Ask a Markertek Expert:
800-522-2025 Email

Gra-Vue MIO-DEC-AUD Analog Video & Dual Analog Audio to SDI Converter

Manufacturer: Gra-Vue Co., Ltd.

Item #: GFE-MIO-DEC-AUD   •   MFG #: MIO DEC-AUD




Our Price:$289.00

free ship


Availability: Direct Ship From Manufacturer
i
Item ships directly from the manufacturer. Normal delivery time is 2-7 business days and is subject to manufacturer availability. Need it sooner? Call 800-522-2025, or email Customer Service for expedited delivery options.


  • 2 - 7 Day Normal Delivery Time - Faster Shipping Options at Checkout or Call Us.


Share!





The MIO DEC-AUD is a miniature a universal analo video (CVBS/YUV/Y.C) to SD-SDI converter and an analog audio embedder in a single Box. As well as reducing costs by more than 50% in comparison to rack mount systems this unit is self contained and can be used in the field as well as in studio installations.
The MIO DEC-AUD requires a 12V DC power from an optional AC to DC power supply or 12 V external source, such as a camera or battery. For user confidence and convenience there are two LEDs that indicate the status of source signal and power.


  • Features

    • Convert analog video/audio to embedded SDI
    • Input CVBS/YUV/YC are selectable
    • Output 625i60 & 525i60 are selectable
    • Support NTSC/PAL format
    • Broadcast quality 10 bit video conversion
    • Selectable 20 bit embedding audio
    • Dip switch for set up
    • LED indicators for signal source and power

  • Specifications

    • Analog Video Input:
    • 3 x BNC, 75 Ohm, CVBS/YC/YUV selectable
    • Format: PAL, NTSC
    • Analog Audio Input:
    • 2 x 3pin Phoenix, 110 Ohm, balanced
      Digital Video Output:
    • 2 x BNC, 75 Ohm, SDI
    • Standard: SMPTE 259M-C; 270Mb/s
    • Video Format: 525i60, 625i50
    • Amplitude: 800mV±5%
    • Jitter: <0.2UI
      Status Indication:
    • Power & Input locking
    • Dimension: 124.5 x116.5 x30mm
    • Power: 12VDC 1.0A
    • Working Temp.: 5 °C - 25 °C

  • Item Includes

    • 12VDC power adapter, 2 x 3 pin pheonix male connectors
