    HD-NDI-X20 - Overview

    The ultimate POV NDI®HX one man army
    The HD-NDI-X20 gets the best of both worlds in our POV and PTZ world; form-factor, and zoom. The camera boasts a beautiful Full-HD 20x optical zoom module, which outputs crisp 1080 60p video over HDMI, NDI|HX, and IP.

    With that said, dim the lights, pull up the feed and zoom in on the action!

    No-Hassle Integration
    The HD-NDI-X20 comes pre-loaded with its NDI|HX license key. That means less time figuring out whether the activation key has an I or l, and more time streaming.

    1 Cable to rule them all
    With PoE support, simplify your cable setup with just 1 ethernet cable. Power, Control, Video just like that! As we like to say; less mess, less stress.

    The beauty of range!
    Having the versatility of 20x optical range gives you the power to capture subjects up to 100ft over NDI®|HX and other streaming protocols, clearly!

    No Complex Web UI Here
    With a simple control, preview, and image settings web UI, you can get to streaming immediately!

    Tally light - ON!
    Let your talent know what camera to look for with its integrated tally light! Automatically working when NDI®|HX is being pulled into your software.

    1/4"-20 Mount Here, and There
    This beast of a camera comes packed with two 1/4" - 20 mounting holes, on the top and bottom of the center of the camera, making it safer, and easier to mount!

    • Features:

      • Contains a Sony CMOS ISP (1/2.8" progressive CMOS sensor) providing up to 1920x1080 full HD resolution.
      • Utilizes the newest NDIr|HX2 for the lowest latency, quality and compression video over a single network.
      • Autodiscover enabled for fast installation over any network.
      • 20X optical zoom allowing for a wide angle of 61° and tele'd 3.4°
      • Full HD video over HDMI, RTSP, RTMP, and NDI.
      • Fully adjustable camera settings, from White balance, exposure settings, and image parameters.
      • Supports PoE: get power and video over one ethernet cord.
      • Controllable over RS485 or online web UI.
      • Menu based image parameters controllable over breakout cable or web UI.
      • Free firmware updates when needed.
      • Mountable tripod holes on the top and bottom

    • Specifications:

      • Video Interface: HDMI (V1.4) | RJ-45 | NDIr|HX2
      • Sensor: 1/2.8" Sony Progressive CMOS Sensor
      • Zoom Module: 20X Optical Zoom Module
      • Zoom: FOV 61°~ Wide, 3.4° Tele'd
      • Video Format HDMI: 1920 x 1080: 60p/59.94p/50/30p/29.97p/25p/24p/23.98p, 1920x1080: 60i/59.94i/50i, 1280x720: 60p/59.94p/50p/30p/29.97p/25p
      • Video Format IP/NDI|HX (Frames): 1920x1080: 60p/59.94p/50/30p/29.97p/25p/24p, 1024x720: 60p/59.94p/50/30p/29.97p/25p/24p
      • Control Port: RS485, RJ-45 (VISCA over IP), NDI
      • Network Speed: 1000M
      • Video Encode: H.264/H.265
      • Bit-Rate Control: Variable Bit Rate, Constant Bit Rate
      • Video Bit Rate: 1024 kbps (min) ~ 16384 kbps (max)
      • IP Protocol: IP, RTSP, RTMP, VISCA over IP, NDIr|HX2
      • POE+: PoE+ Supported (IEEE802.3at) 24V 30W
      • Minimum Lux: 0.01 Lux
      • White Balance: Auto/Indoor/Outdoor/One Push/ATW/Manual
      • Exposure: Auto/Manual
      • Gamma: Supported
      • WDR: Supported
      • BLC: Supported
      • 2D/3D NDR: Supported
      • Audio: TRS Stereo Line In (3.5mm Jack)
      • Dimensions LWH: 6.73" x 2.5" x 2.5"

    • Item Includes:

      • 1x HD-NDI-X20
      • 1x Power adapter
      • 1x Power adapter sockets
      • 1x Micro USB cable

    • GTIN:

      0783970764881
