Alfatron ALF-EXT60IR18G Cost Effective Point-to-Point HDMI and IR Signal Extender

ITEM #: ALF-EXT60IR18G MFG #: ALF-EXT60IR18G

  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
free ship

List Price:

$278.00

Our Price:

$259.99

Special Price:

$199.00

Availability: In Stock
iAvailability Description Popup


    ALF-EXT60IR18G - Overview

    The Alfatron EXT60IR-18G is a cost-effective point-to-point extender set for HDMI 2.0 and IR signals. This kit supports 4K/UHD video @ 60 Hz with 4:4:4 Chroma sampling, as well as HDMI data rates up to 18 Gbps, HDCP 2.2 compliant and HDR. It provides HDMI transmission up to 230 feet (70 meters) for [email protected] 4:4:4 and 330 feet (100 meters) at 1080p, over single CAT5e/6 cable. It supports video resolution down-scaling: the 4K input can be automatically downscale to 1080p output for compatibility with 1080p display.

    • Features:

      • Extend HDMI 2.0 signal over Cat5e/6, supports up to [email protected], 4:4:4 HDR, 18G, HDCP 2.2
      • Range of 230ft (4K) up to 330ft (1080p)
      • Supports downscaling for connecting 4K sources to 1080p displays
      • HDMI loop output on TX unit
      • Bi-directional IR pass-through
      • EDID pass-through
      • Compact design is simple to operate

    • Specifications:

      • TX Unit
      • Video input: HDMI x1
      • Video loop out: HDMI x1
      • IR input: 3.5mm x1
      • IR output: 3.5mm x1
      • Extender output: RJ45 x1
      • Power: 12V DC

        RX Unit
      • Video output: HDMI x1
      • IR input: 3.5mm x1
      • IR output: 3.5mm x1
      • Extender input: RJ45 x1
      • Power: 12V DC

    • Item Includes:

      • 1x TX Unit
      • 1x RX Unit
      • 1x Power supplies
      • 1x Operation manual

    • Warranty:

      • 7 years
