Atomos SHINOBI7 7 Inch 4K HDMI/SDI HDR Photo & Video Monitor

ITEM #: ATO-SHINOBI7 MFG #: SHINOBI7

  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
free ship

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

Our Price:

$699.00

Availability: In Stock
iAvailability Description Popup


    SHINOBI7 - Overview

    The Atomos Shinobi 7 is the perfect 7" HDR monitor that allows any content creator to have complete control over the image being captured.

    Bigger and brighter than its 5- inch counterpart, the Shinobi 7 delivers next level display quality and control functionality to our monitor- only range. With 2200 Nits brightness, the potential for cross conversion and camera control, and all of the on- screen monitoring functionality the Atomos products are known for.

    BIG, Bright and Beautiful
    Shinobi 7 combines a large 7" HDR screen with a calibrated peak brightness of 2200Nits and the lightweight Monitor-only functions of the original Shinobi. The Shinobi 7 can be used in the brightest of environments to monitor signals up to 4Kp60 via HDMI. An ideal directors' monitor, focus pullers' monitor, program or preview display for video switchers and perfect for vloggers presenting to camera.

    Camera Controls at the Fingertips
    Control camera functions with the intuitive touchscreen of the Shinobi 7, designed to give you fast access to the most crucial camera features. The optional Atomos USB-C to serial cable gives you direct control of all the menu configurations on Z Cam E2 series cameras, so that you can focus on the beautiful image and make dynamic adjustments of iris, white balance, shutter angle and ND.

    Perfect For:
    Shinobi 7 marks the return of an SDI and HDMI monitor- only solution to the Atomos range, opening up the well- established Shinobi family to a wider target audience:
    - As a director's monitor for remote viewing
    - For `box cameras' with no monitor, that record internally
    - As a larger on- camera monitor for live monitoring for influencers and Youtubers
    - For underwater filming
    - For focus pullers
    - For any outdoor filming
    - For existing Shinobi users looking for a larger monitor

    • Features:

      • 2200Nits HDR & Daylight Viewable Display
      • 1920 x 1200 16:10
      • HDMI 2.0 4k DCI p60
      • 3G 2K DCI p60 construction
      • 3 Year extended warranty
      • AtomOS & AtomHDR
      • Waveform, RGB, Histogram
      • Analysis Mode - multi-scope view
      • 3D LUT - monitor & loop out
      • HDMI <=> SDI Cross Conversion
      • Camera Control with compatible cameras via Optional cables

    • Specifications:

      • Physical Specifications
      • Weight (Monitor Only): 577g / 1.04lb (excluding batteries)
      • Dimensions (Monitor Only): 198mm x 133mm x 39mm
      • Mount Points: 1 x Anti rotation 1/4" / 3/8 top and bottom

        Construction
      • Body: Polycarbonate ABS Plastic
      • Cooling: Actively controlled fan and heat sink
      • Multi-function Button: Power / lock screen

        Power
      • Input voltage (battery): 6.2V to 16.8V
      • Battery Voltage: 7.2V
      • Operating Power: 5.8-7.2V
      • Compatible Batteries: 2 x NPF L series
      • Battery Run Time: 5200mAh - up to 2hrs, 7800mAh - up to 3hrs
      • DC In: Locking DC jack
      • Continuous power: Dual battery slots
      • DTAP: Via optional DTap to DC cable

        Display
      • Touchscreen: SuperAtom IPS panel (capacitive touch)
      • Size: 7"
      • Resolution: 1920 x 1200
      • PPI: 325
      • Bit Depth: 10-bit (8+2 FRC)
      • Backlight: Edge lit
      • Brightness (cdm2 /Nits): 2200 +/- 10%
      • Aspect Ratio: 16:9 Image Display
      • Color Gamut: Rec.709
      • Calibration Support: Atomos Calibrator with Xrite i1 Display Pro / Plus (Retail)

        Technology
      • 3D LUT Display: .Cube Format
      • 3D LUT Down: Stream Loop out - HD only
      • 3D LUT: 50/50 Yes
      • Monitoring Modes: Native / HLG / PQ / 3D LUT
      • HDR Output Conversion: HLG / PQ

        Video Input
      • HDMI: 1 x HDMI (2.0) 4Kp60
      • SDI: 1 x 3G SDI - 2k p60
      • Bit: Depth 8 / 10-bit
      • Video Chroma Subsampling: YCbCr 420 & 422

        Video Output
      • HDMI: 1 x HDMI (2.0) 4Kp60
      • SDI (Play Out): 1 x 3G SDI - 2Kp60

        Video Signal Conversion
      • HDMI to SDI: Yes
      • SDI to HDMI: Yes
      • Audio In/Out
      • HDMI: 2ch 24-bit, input dependent
      • SDI: 8ch 24-bit, input dependent
      • Headphone out: 3.5mm 2ch.
      • Embedded: HDMI and SDI

        Supported Codecs & Frame Rates (Record & Playback)
      • Supported Resolution & FPS (Monitor Only):
      • 4K DCI: HDMI: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p
      • 4K UHD: HDMI: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p
      • 2K DCI 2046 x 1080: SDI: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p
      • FHD 1920 x 1080 Progressive: HDMI and SDI : 23.98/24/25/29.9/30/50/59.94/60p
      • FHD 1920 x 1080 Interlaced: 50/

        Supported Media
      • SD: SD Card slot for LUTs / Firmware
      • File System: ExFAT

        On Screen Tools
      • MultiScope Analysis: View Image, selectable Waveform, Histogram, Vector
      • Scopes and Audio bars
      • Waveform: Yes, 3 size / Position
      • Histogram: Luma and RGB
      • RGB Parade: Yes, 3 size / Position
      • Vector Scope: Yes, 2 size / Position and zoom
      • Magnification: 1 x Zoom, 2 x Zoom, 4x Zoom
      • Focus Peaking: Color selected / focus assist sharpening /
      • threshold setting / color / Mono / edges only
      • False Color: Yes
      • Zebra: Yes, adjustable
      • Isolate Color Channel: Blue Only
      • Cine Frame Guides: 2.4:1, 2.35:1, 1.9:1, 1.85:1, 4:3
      • Social Frame guides: 9:16, 1:1, 191:1, 4:5
      • Safe Areas Action and Graphic
      • Grid Markers: 9 Grid
      • Anamorphic Desqueeze: 1.25x 1.33x , 1.5x ,1.8x ,2x
      • Display Flip: Vertical and Horizontal selfie mode

        Onboard Processing
      • 4K UHD Downscale for HD: Yes
      • DCI Crop: Yes

        External Device Control
      • Serial 2.5mm Jack: USB-C to Serial (ATOMCAB018)
      • USB: Camera control for supported cameras in future firmware release
      • RJ45: Camera control for supported cameras in future firmware release

    • Item Includes:

      • 1x Shinobi 7
      • 1x International DC Power Adaptor
      • 1x Quick Start Guide

    • Warranty:

      • 1 Year, Extended to 3 Years on Registration

    • GTIN:

      0814164022576
