Blustream HEX100CS-RX HDBaseT HDMI 18G Extender RX - 70m (1080p 100m)

HEX100CS-RX - Overview

• Features:

  • Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
  • Advanced Color Space Conversion (CSC) supports HDMI2.0 18Gbps specification including HDR
  • Supports 4K @ 60Hz 4:4:4 UHD video up to 70m
  • Extends HDMI 1080p video up to 100m
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Supports all known digital HDMI audio formats including Dolby TrueHD, Atmos; DTS-HD Master Audio and DTS:X transmissions
  • HDMI re-clocking to help solve HDMI, HDCP, compatibility and handshaking issues
  • HDMI audio breakout to analog L/R audio and coaxial digital outputs concurrently
  • Supports bi-directional RS-232 pass through
  • Supports bi-directional IR pass through
  • Advanced EDID management
  • HDCP2.2 compliant


• Specifications:

  • Audio Output Connectors: 1 x RCA (S/PDIF) & 2 x Analog RCA (Left / Right)
  • IR Output ports: 1 x 3.5mm mono jack
  • IR Input ports: 1 x 3.5mm stereo jack
  • RS-232 serial port: 1 x DB-9 female
  • Video Output Connectors: 1 x HDMI Type A, female
  • Video Input Connectors: 1 x HDBaseT™ RJ45 connector
  • Power Supply: 12V/2A DC, screw type connector (not supplied)
  • Power Consumption: 5.6W
  • Unit Dimensions (W x D x H): 113 x 124 x 22mm (without connections)
  • Unit Dimensions (W x D x H): 113 x 138 x 22mm (with connections)
  • Unit Weight: 0.35kg (excluding accessories)
  • Carton / Box Dimensions (W x D x H):mm
  • Shipping Weight: 0.5kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature: -4°F to 140°F (-20°C to 60°C)


• Item Includes:

  • 1x HEX100CS-RX
  • 1x Mounting Kit


• Warranty:

  • 3 Year Warranty


• GTIN:

  9340242002686
