Blustream IP250UHD-RX IP Multicast HDMI UHD Video Receiver over 1Gb Network with Bi-directional IR / RS-232 & USB

ITEM #: BLU-IP250UHD-RX MFG #: IP250UHD-RX

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Free Shipping with $49 Minimum Order

Item unavailable. Please select another option.

Ask a Markertek Expert if you need assistance finding an appropriate substitute.

Our Price:

$1,448.00

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    IP250UHD-RX - Overview

    UHD Multicast distribution platform allows virtually latency free (1 frame) distribution of HDMI video over a 1Gb Network. Compatible with the current IP200 platform, the Bluestream IP250UHD-RX is an industry leading 4K HDCP 2.2 HDMI video scaling receiver that using visually lossless compression technology delivers HDMI, Bi-directional IR, RS-232 & USB/KVM up to lengths of 100m over standard network architecture, or greater distances using the in-built Fiber SFP port.

    The IP250UHD-RX features dual RJ45 network ports for independent or combined HDMI and/or Dante signal distribution. The unit can be powered via PoE from the network switch or locally should the switch not support PoE. With multiple configuration options available, the Multicast solution is ideal for both commercial and residential installations.

    • Features:

      • Advanced UHD video over 1Gb Network
      • Operates as a stand-alone system, or together with existing IP200UHD products
      • Virtually unlimited system size
      • Extends HDMI and Dante up to a distance of 100m over a single CAT cable
      • Dual RJ45 network ports configurable for independent or combined HDMI and Dante signal distribution
      • SFP port for independent or combined HDMI and Dante signal distribution over a single fiber cable
      • Video up-scaling and down-scaling
      • Supports up to 4K 30Hz UHD video output
      • In-built 2ch Dante transmitter for breakout of audio from HDMI source or local analog audio input
      • In-built 2ch Dante receiver for embedding of audio onto the HDMI signal or breakout to local analog audio output
      • Optical (S/PDIF) audio input for conversion of digital audio format onto Dante audio system
      • Analog L/R audio outputs support both balanced and unbalanced audio signals
      • Supports all known HDMI audio formats including Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio transmission
      • Advanced signal management for independent routing of IR, RS-232, USB/KVM, audio and video
      • OLED front panel display for advanced system information and manual configuration
      • PoE (Power over Ethernet) to power Blustream products from PoE switch
      • HDCP 2.2 compliant with advanced EDID management
      • Local 24V 1A power supply should Ethernet switch not support PoE (not included)

    • Specifications:

      • Video Input Connectors: 1 x LAN RJ45 connector
      • Video Output Connectors: 1 x HDMI Type A, female
      • Audio Input: 1 x Optical (S/PDIF)
      • Audio Output Connectors: 1 x 5-pin Phoenix connector
      • Ethernet Port: 2 x LAN RJ45 connector
      • Fiber Port: 1 x SFP connector (fiber module not supplied)
      • RS-232 Serial Port: 1 x 3-pin Phoenix connector
      • USB/KVM Port: 2 x USB-Type A
      • IR Input Ports: 1 x 3.5mm stereo jack
      • IR Output Ports: 1 x 3.5mm mono jack
      • Firmware Update: 1 x Micro-USB
      • Operating Temperature: 32°F to 104°F (0°C to 40°C)
      • Storage Temperature: -4°F to 140°F (-20°C to 60°C)
      • Unit Dimensions (without connections): 190mm x 126mm x 25mm
      • Unit Dimensions (with connections): 190mm x 164mm x 25mm

    • Item Includes:

      • 1x IP250UHD-RX
      • 1x IR Receiver
      • 1x IR Emitter
      • 1x Serial 3-pin phoenix connector
      • 1x Mounting kit
      • 1x Quick Reference Guide
