BON BXM-173T3G 17.3 Inch 3G/HD/SD-SDI & HDMI LCD Studio Broadcast & Production Monitor with PIP/ Waveform & Vectorscope
  • BON BXM-173T3G 17.3 Inch 3G/HD/SD-SDI & HDMI LCD Studio Broadcast & Production Monitor with PIP/ Waveform & Vectorscope
  • BON BXM-173T3G 17.3 Inch 3G/HD/SD-SDI & HDMI LCD Studio Broadcast & Production Monitor with PIP/ Waveform & Vectorscope
  • BON BXM-173T3G 17.3 Inch 3G/HD/SD-SDI & HDMI LCD Studio Broadcast & Production Monitor with PIP/ Waveform & Vectorscope
  • BON BXM-173T3G 17.3 Inch 3G/HD/SD-SDI & HDMI LCD Studio Broadcast & Production Monitor with PIP/ Waveform & Vectorscope
  • BON BXM-173T3G 17.3 Inch 3G/HD/SD-SDI & HDMI LCD Studio Broadcast & Production Monitor with PIP/ Waveform & Vectorscope

Questions? Ask a Markertek Expert:
800-522-2025 Email

BON BXM-173T3G 17.3 Inch 3G/HD/SD-SDI & HDMI LCD Studio Broadcast & Production Monitor with PIP/ Waveform & Vectorscope

Manufacturer: Bon Electronics

Item #: BON-BXM-173T3G   •   MFG #: BXM-173T3G



List Price:$3,679.00
Our Price:$3,499.00

free ship


Availability: Usually ships in 3-10 business days
i
This item is currently out of stock and will ship the minute we receive it – typically 3-10 business days. Need it sooner? Expedited delivery options may be available. Email [email protected] or call customer service at 800-522-2025 and we'll make it happen.




    Share!





    BXM-173T3G is a high-end 12-bit video processing montior which has picture-in-picture, picture-by-picture, fast SDI switching mode, and many others. The 12bit signal processor displays smooth gradient with high-performance 12-bit video processor. 3D-LUT offers many color spaces such as NTSC, EBU, SMPTE, BT.709, so that the user can choose one for each need. Picture in Picture and/or Picture by Picture allows for a picture displayed inside another picture or two pictures are displayed side by side.


    • Features

      • 12-bit Signal Processing for Smooth Gradients
      • Multiple Color Spaces: NTSC, EBU, SMPTE, BT.709
      • Picture in Picture and Picture by Picture
      • Gen-Lock
      • 8~16 Channel Audio Level Meter
      • UMD/IMD Mode (supports TSL 4.0)
      • Tally Display
      • Monitor Controllable via Ethernet
      • Made in Korea

    • Specifications

      • LCD
      • Size: 17.3"
      • Resolution: 1920 x 1200
      • Pixel Pitch: 0.199mm
      • Color: 10 bit
      • Viewing Angle: 178(H), 178(V)
      • Luminance of White: 300 cd/m²
      • Contrast: 800 : 1
      • Back Light: LED
      • Display Area (H x V): 381.9 x 214.8 mm

      • Input
      • 2 x SDI: HD/SD-SDI, 3G/1.485G/270M
      • 3 x SDI: Analog(YPbPr/CVBS/S-Video/RGB)
      • 1 x HDMI: HDMI (with HDCP v.1.1), 19pin Female
      • 1 x DVI: DVI-I, 24pin, Female
      • 1 x SDI: External Sync, Black Burst & Tri-sync, 1.0Vp-p

      • Output
      • 2 x SDI: SDI-1/2 Active Loop Output
      • 3 x SDI: Analog(YPbPr/CVBS/S-Video/RGB)
      • 3 x SDI: Analog(YPbPr/CVBS/S-Video/RGB)
      • 1 x SDI: For External Synchronization
      • Composite: 1.0Vp-p(with sync), NTSC/PAL
      • S-Video(Y/C): Y :1.0Vp-p, C:0.286Vp-p
      • Component(Y/Pb/Pr): Y :1.0Vp-p, Pb :0.7Vp-p, Pr :0.7Vp-p
      • Component (R/G/B): G :1.0Vp-p(with Sync), B :0.7Vp-p, R :0.7Vp-p
      • PC-RGB,Sync Level: R, G, B : 0.7Vp-p, H/V Sync : 4V ± 1Vp-p

      • Input Formats
      • SMPTE 425M AB: 1080p (60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF), 1080i (60/59.94/50)
      • SMPTE 372M: Dual HD-SDI YCbCr (4:2:2), 1080p, Dual HD-SDI YCbCr/RGB (4:4:4), 1080i, 1080p, 720p
      • SMPTE 274M/292M: 1080i (60/59.94/50), 1080p(30/29.97/25/24/24sF/23.98/23.98sF)
      • SMPTE 296M: 720p(60/59.94/50)
      • SMPTE 260M: 1035i(60/59.94)
      • SMPTE 125M/259M: 480i(60/59.94), 576i(50)
      • 2K, SMPTE 428M: 2048 x 1080p(24/24sF/23.98/23.98sF)
      • ITU R-BT.656: 576i(50)
      • HDMI: ~ 1080p(60)
      • DVI: ~ 1080p(60)

      • Audio
      • 1 x Phone Jack In: Line In(Stereo)
      • 2 x Phone Jack Out: Line Out(Stereo), Headphone Out(Front, Stereo)
      • 2 x Speaker Out: 2W+2W, Stereo

      • General
      • 1 x Ethernet: Control/Update, GPI-7 Port, RJ-45P Jack
      • 2 x GPIO: GPI-7 Port, RJ-45P Jack
      • 2 x Serial: RS-422, RJ-11P Jack
      • 1x USB: For firmware update
      • Power Requirements: AC100-230V(50/60Hz)
      • Power Consumption: 42W
      • Operating Temperature: 0°C ~ 40°C
      • Operating Humidity: 20% ~ 80% RH

      • SPECIFICATIONS:
      • Shipping Dimensions: 17.2 x 21.7 x 9.7 in.
      • Shipping Dimensions (Metric): 43.6 x 55.1 x 24.6 cm
      • Shipping Weight: 18 lbs
      • Shipping Weight (Metric): 8.1 kg

    • Warranty

      • 1 Year
