Datavideo SE-1200MU 6-Input 1080i HD Rackmount Video Switcher with HD-SDI and HDMI Inputs
  • Datavideo SE-1200MU 6-Input 1080i HD Rackmount Video Switcher with HD-SDI and HDMI Inputs
  • Datavideo SE-1200MU 6-Input 1080i HD Rackmount Video Switcher with HD-SDI and HDMI Inputs

Questions? Ask a Markertek Expert:
800-522-2025 Email

Datavideo SE-1200MU 6-Input 1080i HD Rackmount Video Switcher with HD-SDI and HDMI Inputs

Manufacturer: Datavideo Corporation

Item #: DV-SE-1200MU   •   MFG #: SE-1200MU




Our Price:$1,499.00

free ship


Availability: Usually ships in 3-10 business days
i
This item is currently out of stock and will ship the minute we receive it – typically 3-10 business days. Need it sooner? Expedited delivery options may be available. Email [email protected] or call customer service at 800-522-2025 and we'll make it happen.




    Share!

    California Residents:
    8pt-triangleWARNING:
    Cancer and Reproductive Harm - www.P65Warnings.ca.gov





    If you're ready to step up your live video production, the Datavideo SE-1200MU HD video switcher is ready for you whether you are doing an Esports shoot, live streaming a conference, conducting an outside broadcast or a traditional studio shoot.

    Seamlessly switch between 6 different 1080i video sources including both HDMI and 3G-SDI and blend high-quality digital content on the go. The Datavideo SE-1200MU a compact computer controlled 1RU rack mountable switcher. It features real-time stream out multi-view screen video to a control PC for monitoring and control remotely. It is designed to be fully controlled from any Windows Laptop / PC with the included SE-1200 software control panel, or the Datavideo RMC-260 control panel.

    SE-1200MU includes four HD-SDI (1080i / 720p) and two HDMI inputs (RGB/YUV,
    1080i / 720p) and an internal frame synchronizer so you can use sources without gen-lock such as consumer HDMI cameras or even computers for live PowerPoint presentations.

    Two assignable HD-SDI and two HDMI outputs for connecting an HD recorder, monitor and a streaming encoder, plus two Balanced XLR audio inputs for connecting an external audio mixers. Other features include chromakey, lumakey, DSK, PIP, still stores, audio delay, tally and RJ-45/RS-232 remote control interface.


    • Features

      • 6 video inputs ( SDI x 4 + HDMI x 2) - Frame Sync on each input
      • Flexible Mix/Effects Processor with
      • 2 Upstream Keyers, supporting Chroma Key & Linear/Luma Key
      • 2 DSK, supporting Linear & Luma Key Modes
      • 1 PIP (assignable to any of the 4 keyers
      • Wipe Generator: 32 Wipe Patterns, including Circle & Heart | Borders & Softness Control
      • Wipe, Mix & Cut Transitions
      • Full M/E Preview function
      • Any Input (1-6) can be used as a Frame store (Stills Store): Upto 24 images stored on SD Card
      • Assignable Outputs
      • Each SDI output can be switched in the Menu as:
      • - PROGRAM (w/ DSK)
      • - Clean PROGRAM (w/o DSK)
      • - Clean PREVIEW (w/o DSK)
      • - MULTISCREEN
      • - Input 1-6
      • XPT (Cross Point Assignment)
      • PC & Tablet control
      • Remote streaming of Multi view out using built-in Motion JPEG Streaming processor
      • Tally output
      • GPI output
      • 1U rack mount

    • Specifications

      • Connections
      • Total Video Inputs 2 HDMI + 4 SDI
      • Total Outputs 1 HDMI + 2 SDI
      • SDI Video Input 4 (1080i / 720p)
      • HDMI Video Input 2 HDMI (RGB/YUV)
      • 1080i / 720p
      • SDI Audio Output (PGM) 2CH
      • Analog Audio Input 2CH XLR
      • Embedded Audio HDMI & SDI
      • Internal Frame Synchronizers 6 All Inputs
      • PGM Out HDMI / SDI
      • Multi-view Out HDMI (720p->720p ; 1080i->1080p)
      • SDI (720p->720p ; 1080i->1080i)
      • Output can select any of input source PROGRAM (w/ DSK)
      • Clean PROGRAM
      • PREVIEW (w/o DSK)
      • MULTISCREEN
      • Input 1~4
      • Audio Indicator on Multi view Yes (output 2CH)
      • Tally Out Yes
      • GPI Yes (Level / Pulse Trigger selectable)
      • Software Updates Ethernet
        Standards
      • HD Format Support 1080i/50, 1080i/59.94, 1080i/60, 720p/50, 720p/59.94, 720p/60
      • SDI Compliance SMPTE 292M (SDI output / PGM out)
      • Video Sampling 4:2:2 10-bit
      • Color Precision 4:2:2 10-bit
      • Color Space 4:2:2 YUV
      • HDMI Input Resolutions for Computers 1280x720 59.94Hz 50Hz (720p)
      • 1920x1080 59.94Hz 50Hz (1080p & 1080i)
        Processing
      • Colorspace Conversion Hardware based real time
      • Processing Delay Less than 1 frame
      • Audio Mixer selectable audio follow video,
      • master gain control
      • Extras
      • Downstream Keyers 1
      • Linear/Luma Keyers 3 (M/E Keyer, PIP, DSK)
      • Chroma Keyers 2 (M/E Keyer & PIP)
      • Pattern Generators Colour Bar
      • PIP 1
      • XPT Yes
      • Frame store Total 24 stills on internal SD card;
      • One dedicated still buffer, one dedicated freeze buffer;
      • Also, any input can be used as Frame store;
      • 3 Still frames stored in local frame buffers for instant access
      • Control Panel Compatibility Use PC via Ethernet; Control panel
      • Input Voltage 12V
      • Power consumption 23W
      • Operating Temperature 0-50 deg. Celsius at 10%-80% Humidity
      • Control Protocol DVIP
      • Multi View Monitoring
      • Number of Windows 2 (PGM, PVW)
      • +6 (Inputs 1-4, Stills & Freeze)
      • +2 Output windows (SDI1, SDI2)
      • Routable Windows Yes (Follow XPT)
      • Tally Yes
      • Windows Source Labels Yes

    • GTIN:

      0672255006665
