Datavideo TLM-700UHD 7 Inch 4K 50/60P LCD Monitor

ITEM #: DV-TLM-700UHD MFG #: TLM-700UHD

  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
free ship

Our Price:

$299.00

Availability: Typically Ships in 3-10 Days
iAvailability Description Popup


    TLM-700UHD - Overview

    4K 50/60P Amazing Details
    Datavideo's TLM-700UHD LCD Monitor accepts 4K 50/60p inputs and displays them on a 7" screen. The monitor is a 1920x1080 Full HD panel which provides 170° of viewing angle. The field monitor supports both DCI 4K and Ultra HD signal inputs and outputs.

    7'' 4K Look-Back Monitor
    Supports 4K/3G/HD/SD 1920x1200 panel resolution.

    Simple Input and Output Configuration
    1x HDMI input and loop out

    Compatible with Professional Cameras
    Compatible with DSLRs, mirrorless cameras, and camcorders

    Fast and Accurate Focus Peaking
    The red/green/blue peaking profile helps users instantly determine proper focusing.
    Peaking zones can be shown during shooting, recording, and playback.

    Over-Exposure Analysis
    Exposure analysis lets users see if the brightness is too strong in certain regions of the video.

    Color Field Checking
    Provides monochrome, red, green and blue-only mode for easy color recognition and correction

    Screen Flip Function
    Supports both vertical and horizontal rotation. Compatible with tripods, arms, and cages. Convenient for viewing from multiple angles.

    Zoom In
    Zoom in 1.5X / 2X / 3X / 4X
    Clearly view the details of image for instant adjustment

    Safety Marker and Aspect Marker
    Simulates the effect of cropping in post-production. Support vertical mode, too. Safety marker 95% / 93% / 90% / 88% / 85% / 80% and aspect maker 16:9 / 1.85:1 / 2.35:1 / 4: 3 / 3:2

    • Features:

      • Supports brighter and sharper 4K 50/60P inputs and outputs
      • 1920x1080 Full HD panel which provides 170° of viewing angle
      • Compatible with DSLRs, mirror-less camera, and camcorder.
      • IPS high resolution faithful interpretation
      • White balance setting 6500K / 7500k / 9300k / customize
      • Zoom in 1.5X / 2X / 3X / 4X

    • Specifications:

      • Screen: 7" TFT LCD
      • Chassis: Camera Mount
      • Resolution: 1920x1200
      • Viewing Angle: (H) +85/-85°, (V) +85/-85°
      • Luminance/Contrast: 450cd/m², 1000:1
      • Video Inputs: 1x HDMI (2.0), HDCP 2.2
      • Loop Through: 1x HDMI (2.0)
      • Supported Input Resolutions
        4096x2160p (23.98/24/25/29.97/30/50/59.94/60Hz)
        3840x2160p (23.98/24/25/29.97/30/50/59.94/60Hz)
        2048x1080p (50/59.94/60Hz)
        1080p (23.98/24/25/29.97/30/50/59.94/60Hz)50i/59.94i/60i)
        1080i (50/59.94/60Hz)
        720p (23.98/24/25/29.97/30/50/59.94/60Hz)
        576i(50Hz), 576p(50Hz),
        480i(59.94/60Hz), 480p(59.94/60Hz)
      • Aspect Ratio: Full/16:9/1.85:1/2.35:1/4:3/3:2
      • Aspect Marker: Full/16:9/1.85:1/2.35:1/4:3/3:2
      • Safety Marker: Off/95%/93%/90%/88%/85%/80%
      • Audio In/Out: Embedded Audio (48KHz sampling), Analog Stereo (Phone Jack), Speaker x1 (2W)
      • Special Features
        Focus assist (peaking)
        False Color
        Histogram
        Exposure
        Pixel to Pixel Zoom
        Underscan
        Check Field (blue-only mode, mono chrome mode)
      • Dimension (LxWxH): 182 x 129 x 37 mm
      • Weight: 0.3 kg
      • Operating Temp. Range: 0~40 °C
      • Power: DC 12V, 12W

    • Item Includes:

      • 1x TLM-700UHD product
      • 1x AD Switch DC 12V
      • 1x Folding sun shade cover
      • 1x HDMI A/C cable
      • 1x Battery plate
      • 1x Hot shoe mount
      • 1x Thank You Card
