Gefen GTV-COMPSVID-2-HDMIS Composite to HDMI Scaler

ITEM #: GEF-CS-2-HDMIS MFG #: GTV-COMPSVID-2-H

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the GEF-CS-2-HDMIS

GTV-COMPSVID-2-H - Overview

Transform Composite or S-Video into crisp, scaled HDMI video!

The GefenTV Composite to HDMI Scaler from Gefen allows you to upscale composite video or S-video input to digital HDMI video output. Audio output can be embedded with the HDMI signal or separate. It supports resolutions of up to 1080p or 1920 x 1200. Input resolution is automatically detected and output resolution is selectable.

Composite or S-Video to HDMI Scaling Use this device to scale composite video or S-video to HDMI.
Audio Audio output can be embedded with the HDMI signal or managed separately.
Resolution This device supports resolutions up to 1080p or 1920 x 1200.
Input & Output Input resolution is automatically detected and output resolution is selectable.

  • Features:

    • 48MB frame buffer for frame rate conversion
    • Input resolution is automatically detected while the output resolution and refresh rate can be selected via the on-screen display (OSD) menu system and front panel push-buttons
    • Inputs S-Video or Composite

  • Specifications:

    • Input (1) S-video mini-DIN, (1) composite video RCA jack.
    • Output (1) HDMI type A 19-pin female, (1) right-left stereo audio.
    • Bandwidth Digital Maximum Pixel Clock: 165MHz.
    • Input Signal Input DDC Signal: 5Vp-p (TTL).
    • Resolution Up to 1080p or 1920 x 1200.
    • Power 5VDC, 10W maximum.
    • Dimensions (HxWxD) 1 x 5 x 3.5".
    • Weight 2 lbs.

  • Item Includes:

    • Scaler
    • 6' 3 RCA Cable (M-M)
    • 5VDC Power Supply
    • User's Manual
    • Two-Year Warranty Against Defects in Material & Workmanship

  • GTIN:

    0845344062808


GTV-COMPSVID-2-H - Required Accessories
