ikan IKC-AS2H Advanced 3G-SDI to HDMI Converter

ITEM #: IKAN-IKC-AS2H MFG #: IKC-AS2H

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the IKAN-IKC-AS2H

IKC-AS2H - Overview

The IKC-AS2H Advanced SDI to HDMI Converter is designed and built for professionals.

The Advanced SDI to HDMI Converter delivers field-tested reliability, solid construction, and all the features required for professional performance.

The IKC-AS2H's features include auto-detecting SD/HD/3GSDI that delivers reliable, consistent performance.

The IKC-AS2H Advanced SDI to HDMI Converter supports 3G SDI (level A/B) and has video monitoring features such as waveform and vectorscope, a video test pattern generator, time code display, up to 8ch HDMI embedded audio, an audio test pattern generator. A 1/4"-20 threaded mounting point is on the bottom of the converter.

  • Features:

    • Supports 3G SDI (Level A/B)
    • Auto Detects SD/HD/3G SDI
    • Video Monitoring Features: Waveform
    • (Single/Parade) and Vectorscope
    • Video Test Pattern Generator: Color Bars & RP219
    • Time Code Display (LTC, VITC1, VITC2, DVITC)
    • Up to 8ch HDMI Embedded Audio
    • Audio Test Pattern Generator (1 to 4kHz)
    • De-embedded 2 ~ 16Ch Audio Level Meters (Horizontal/Vertical)
    • 1/4"-20 Thread on Bottom for Mounting


  • Specifications:

    • Video Outputs: 1 x SDI Loop-Through, 1 x HDMI (with HDCP v 1.1), 19pin Female
    • Audio Output: External Audio Output (Stereo 3.5 pi)
    • Inputs: 1 x BNC (HD/SD-SDI, 3G/1, 485G/270M)
    • Power Consumption: 6W
    • Power Requirements: 4DC (7V-24V) or AC Adapter (100 ~ 230V, 50Hz/60Hz)
    • Dimensions: 4.6 x 3.9 x 1.4"
    • Weight : .8 lb
    • Shipping Dimensions: 12.3 x 10.1 x 2.8"
    • Shipping Weight: 3 lbs


  • Item Includes:

    • 1 X AC Adapter
    • 1 X Power Cord
    • 1 X SDI To HDMI Converter


  • GTIN:

    0847983012374
