Tripp Lite OMNISMART750MX 750VA 460W 120V Line-Interactive UPS with 12 NEMA 5-15R Outlets/Double-Boost AVR/USB

ITEM #: OMNISMART750MX MFG #: OMNISMART750MX

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Tripp Lite
Free Shipping with $49 Minimum Order

List Price:

$258.34

Our Price:

$191.00

Add to Wish ListLeasing Options
Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup
    Report Lower PriceLarge Quantity Quote

    OMNISMART750MX - Overview

    750VA/460W/120V Battery Backup for PCs, Home Theaters or Digital Signage
    This Tripp Lite OMNISMART750MX OmniSmart line-interactive UPS system with AVR protection provides reliable battery backup and AC power protection against blackouts, brownouts, overvoltages, surges and line noise that can damage valuable electronics or destroy data. The 120V battery backup is ideal protection for your home office, media center or commerce components, including computers, routers, printers, HDTVs, Blu-ray players, game consoles, ATMs, security systems and digital signage equipment.

    Allows Time to Back Up Critical Files During a Blackout
    Backup support allows you to work through short power failures and gives you enough time to safely save files and shut down your system in case of a prolonged blackout. Backup time varies according to load, but internal battery should keep a half load (230W) powered as long as 10 minutes and a full load (460W) up to 3.6 minutes.

    12 NEMA 5-15R Outlets Protect Your Connected Components
    Six 5-15R outlets provide battery backup, surge protection and voltage regulation for your computer, monitor and other crucial components. The other six 5-15R outlets provide surge suppression only for printers, speakers and other desktop equipment regarded as non-essential during a blackout. In addition, RJ45 jacks protect a telephone/DSL dial-up or 10BaseT Ethernet connection.

    Double-Boost AVR Corrects Low/High-Voltage Conditions for Enhanced Performance
    A double-boost, single-cut AVR (Automatic Voltage Regulation) circuit, designed specifically for the LATAM region, protects your equipment from incremental hardware damage, data loss and performance problems caused by brownouts and overvoltages. Slight under-voltages as low as 93V are boosted by 13%. More severe brownouts as low as 78V are increased by 35%. A voltage cut of 16% reduces UPS output during overvoltage conditions as high as 152V, all while keeping the battery fully charged and ready to take over in case of power failure.

    600 Joules Fight Back Against Unexpected Power Surges
    A 600-joule surge suppression rating protects connected components from the harmful effects of power surges.

    Designed for High Efficiency to Help You Save Money and Protect the Environment
    A >98.3% efficiency rating reduces BTU emissions, energy consumption and, ultimately, your energy costs.

    • Features:

      • Protects equipment against blackouts, brownouts, transient surges and line noise
      • Keeps AC power running during blackouts to allow time for file saves and safe shutdown
      • Double-boost AVR maintains 120V nominal output during brownouts and overvoltages
      • 12 NEMA 5-15R outlets power and protect PC, home theater or digital signage equipment
      • High >98.3% efficiency and low BTU ratings save electricity and lower your energy costs


    • Specifications:

      • Input
      • Rated input current (Maximum Load): 10A
      • Nominal Input Voltage(s) Supported: 120V AC
      • Nominal Input Voltage Description: Supports input voltages from 78 to 152V
      • UPS Input Connection Type: 5-15P; Right-Angled
      • Input Circuit Breakers: 10A @ 120V
      • UPS Input Cord Length (ft.): 7
      • Input Phase: Single-Phase
      • Input Frequency: 60 Hz (±3%)

        Output
      • Output Volt Amp Capacity (VA): 750
      • Output Watt Capacity (Watts): 460
      • Output Capacity Details: Supports 125% load for 10 minutes, 20 seconds (load PF=1.0); Supports 110% for up to 27 seconds
      • Power Factor: 0.6
      • Nominal Voltage Details: 120v nominal output in AC and battery modes
      • Frequency Compatibility: 60 Hz
      • Frequency Compatibility Details: 60 Hz (±3%) tolerance
      • Output Voltage Regulation (Line Mode): 120V~ (+8% / -15%)
      • Output Voltage Regulation (Battery Mode): 120V (±5%)
      • UPS Output Receptacles (Surge Suppression Only): 6 UPS outlets, 6 surge-only outlets
      • Output AC Waveform (AC Mode): Pure sine wave
      • Output AC Waveform (Battery Mode): PWM sine wave
      • Nominal Output Voltage(s) Supported: 120V
      • Output Receptacles: (12) 5-15R
      • Individually Controllable Load Banks: No

        Battery
      • Full Load Runtime (min.): 3.6 min. (460W)
      • Half Load Runtime (min.): 11 min. (230W)
      • Expandable Runtime: No
      • DC System Voltage (VDC): 12
      • Battery Recharge Rate (Included Batteries): 5 hours to 90%
      • Battery Access: Battery access door
      • Battery Replacement Description: Replaceable internal batteries

        Voltage Regulation
      • Voltage Regulation Description: Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 78 to 152
      • Overvoltage Correction: Input voltages between 128 and 152 are cut by 16%
      • Undervoltage Correction: Input voltages between 93 and 108 are boosted by 13%
      • Severe Undervoltage Correction: Input voltages between 78 and 93 are boosted by 35%

        Surge / Noise Suppression
      • UPS AC Suppression Joule Rating: 600
      • UPS AC Suppression Response Time: Instantaneous
      • UPS Dataline Suppression: 1 line TEL/DSL or Ethernet
      • EMI / RFI AC Noise Suppression: Yes

        Physical
      • Primary Form Factor: Desktop
      • Installation Form Factors Supported with Included Accessories: Tower; Ultra-compact desktop; Wallmount
      • Shipping Dimensions (hwd / in.): 10.71 x 6.30 x 15.00

        Environmental
      • Operating Temperature Range: +32 to +104 degrees F
      • Storage Temperature Range: +5 to +113 degrees F
      • Relative Humidity: 0 to 90%, non-condensing
      • AC Mode BTU / Hr. (Full Load): 30.72
      • AC Mode Efficiency Rating (100% Load): >98.4%
      • Operating Elevation (ft.): Up to 10,000 ft
      • Operating Elevation (m): Up to 3000m

        Line / Battery Transfer
      • Transfer Time: 2-6 milliseconds (typical), 10 milliseconds (max)
      • Low Voltage Transfer to Battery Power (Setpoint): 78
      • High Voltage Transfer to Battery Power (Setpoint): 152

        Standards & Compliance
      • UPS Certifications: ENERGY STAR Qualified; Meets FCC Part 15 Category A (EMI); Tested to CSA (Canada); Tested to EAC (Belarus, Kazakhstan, Russia); Tested to NOM (Mexico); Tested to RETIE (Colombia); Tested to UL1778 (USA)
      • Certification Details: Series Number (s) AG-0553; Safety Standards (Canada) CAN/CSA-C22.2 No. 107.3-14 (3rd Ed)+GI1 (R:2017-10); Safety Standards (U.S.) UL1778:2014 (5th Ed) R10.17; FCC/ICES Compliant CLASS A; 47 CFR FCC PART 15 SUBPART B:2017; ICES-003:2017


    • Item Includes:

      • 1x OMNISMART750MX 750VA 460W 120V Line-Interactive UPS with 12 Outlets
      • 1x USB cable
      • 1x Owner's manual


    • Warranty:

      • 2-year limited


    • GTIN:

      0037332258175
