AW-HR140PJ8 - Overview

The AW-HR140PJ8 is an integrated remote camera system that incorporates an outdoor housing, camera, lens and pan-tilt head and maintains stable shooting performance in the toughest of environments. It is equipped with the same DSP and full HD 3MOS sensors as the AW-HE130 which results in high sensitivity, high S/N ratio, and high resolution due to its advanced video processing.

Features:
- 1/2.86 type full HD 3MOS sensors and Digital Signal Processor (DSP)
- 20x Optical Zoom (plus 1.4x Digital Extender)
- Hybrid Image Stabilizer (mechanical and optical, named DISS) for stable shooting performance
- Protection IP65, salt-resistant paint & includes wipers, heater and defroster (washer optional)
- Full HD Rugged Outdoor PTZ Camera with special functions: Intelligent, Haze Reduction & Night Mode
Specifications:
- Weight: 19.84 Lbs
- Dimensions: 15.6 x 10.15 x 14.06 Inches
- Power Requirements: DC 12 V to 21.8 V (DC IN connector)
- Current consumption: 3.1 A to 5.5 A (DC IN connector)
- Ambient Operating Temperature: -15 °C to 45 °C (5 °F to 113 °F)
- Ambient Operating Humidity: 10% to 100% (no condensation)
- Storage Temperature: -20 °C to 55 °C (-4 °F to 131 °F)
- Storage Humidity: 10% to 95% (no condensation)
- Mass: Approx. 9.0 kg (19.84 lb) (10-5/32 inches x 14-1/16 inches x 15-5/8 inches)
- Finish: Silver, salt resistant coating
- Waterproof and Dust Proof: IP65 compliant
- Maximum Permissible Wind Speed: 15 m/sec: Operates normally
- 50 m/sec: Operation possible
- 60 m/sec: No damage
- Wiper: Installed as standard
- Heater: Installed as standard
- Defroster: Installed as standard
- Controller Supported: AW-RP120G, AW-RP50, AK-HRP200G - It may be necessary to upgrade the version of the
- Imaging Sensors: 1/2.86-type Full-HD 3MOS
- LENS: Optical 20x zoom/10x digital zoom, F1.6 to F3.4
- Focus: Switching between auto and manual
- Focus Distance: Entire zooming range: 800 mm (2.62 ft)
- Wide end: 400 mm (1.31 ft)
- Color separation optical system: 3MOS
- Minimum Illumination: 2 lx (50 IRE, F1.6, 36 dB, without accumulation)
- Horizontal Resolution: 1000 TV lines Typ (Center area)
- Gain Selection: Auto, 0 dB to 42 dB (1 dB steps)
- Frame Mix: 0 dB, 6 dB, 12 dB, 18 dB, 24 dB
GTIN:
0885170357488
