PureLink HUE-100 HDTools 4K60 HDMI and USB-C Switch/Extender - 328 Foot/100 Meter HDBaseT 3.0

ITEM #: PLK-HUE-100 MFG #: HUE-100

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
PureLink
Free Shipping with $49 Minimum Order

Our Price:

$1,999.99

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
Report Lower PriceLarge Quantity Quote

HUE-100 - Overview

The PureLink HUE-100 HDMI and USB-C HDBaseT 3.0 extension system offers full HDMI 2.0b, HDR/HDR10/HDR10+ (High Dynamic Range) 4K@60Hz 4:4:4 up to 100 meters on CAT6a/7 cable . The HUE-100 can also transport 1080P60 8 bit up to 150 meters over CAT6a/7 cable. Manual or automatic selection of HDMI and USB-C inputs is available on front panel controls and API. User defined EDID and extraction of display EDID are easy operations using the HUE-100 simple API.

The HUE-100 provides Dolby Vision, HLG, multi-channel audio, CEC pass-through, bi-directional RS-232 and IR control, and PoC - all with zero loss and zero noise. The HUE-100 also supports Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio plus LCPM. Additionally, the low profile “slim box” enclosure design makes the HUE-100 ideal for limited space installation environments, such as behind flat panel displays and video walls.

  • Features:

    • HDMI and USB-C Inputs
    • Manual or Automatic Input Selection
    • API Control of:
      - Manual / Auto Input Selection
      - EDID Management
      - De-embedded Audio Mute / Unmute
      - Downscaling
    • Resolutions up to 4K/60Hz (4:4:4)
    • HDMI 2.0b
    • HDR /HDR10/HDR10+
    • HDCP 2.3
    • USB 2.0, 1.1
    • Extends 4K/60Hz up to 328 ft. (100m) and 1080p up to 492 ft. (150m)
    • HDBaseT 3.0 Uncompressed Extension
    • High Bandwidth Support - Up to 18 Gbps
    • USB-C Port Charging up to 60W
    • RS-232 Extension
    • Bi-directional PoC
    • Power Either End from the Other
    • Bi-directional IR Extension


  • Specifications:

      Performance
    • Distance:
      - Up to 130ft (40m) at Ultra HD/4K
      - Up to 230ft (70m) at 1080p
    • Resolutions: Ultra HD/4K up to 4096 x 2160 @50/60Hz (RGB 4:4:4, YCbCr 4:4:4, 4:2:2, 4:2:0)
    • Compliance: HDMI 2.0, HDCP 2.2
    • Data Transfer Rate: 18 Gbps
    • RS-232: 1x RS-232 [3-pin phoenix]
    • IR Extension:
      - 1x IR input (3.5mm stereo mini-jack)
      - 1x IR output (3.5mm stereo mini-jack)
    • Power Consumption: 24W (max)
    • Input Power Requirements: AC 100V - 240V, 50/60Hz
    • Power Supply: DC 24V/1A (US/EU standard, CE/FCC/UL certified)
    • Operating Temperature: 32°F - 117°F (0°C - 47°C)
    • Storage Temperature: - 4°F - 140°F (-20°C - 60°C)
    • Relative Humidity: 0% - 90% non-condensing

      Enclosure
    • Product Dimensions: 7.2" x 3.5" x 0.7" (183mm x 88mm x 18mm)
    • Product Weight: 1.0lbs (0.45kg)
    • Product Shipping Dimensions: 12.21" x 7.09" x 2.76" (310mm x 180mm x 70mm)
    • Product Shipping Weight: 7.7lbs (3.5kg)


  • Item Includes:

    • 1x 18Gbps HDMI/USB-C over HDBaseT 3.0 Extender (Transmiter)
    • 1x 18Gbps HDMI/USB-C over HDBaseT 3.0 Extender (Receiver)
    • 1x IR Blaster Cable (1.5 meters)
    • 1x IR Wideband Receiver Cable (1.5 meters)
    • 2x 3pin-3.81mm Phoenix Connector (male)
    • 1x 24V/3.75A Desktop Power Supply


  • Warranty:

    • 5-Years


  • GTIN:

    0817705026361
