PureLink PS-610 6x1 USB-C HDMI HDBaseT 4K60 Seamless Switching & Multi-View Presentation Switcher with Dante

Name: PureLink PS-610 6x1 USB-C HDMI HDBaseT 4K60 Seamless Switching & Multi-View Presentation Switcher with Dante
Brand: PureLink
SKU: PLK-PS-610
Price: 3499.99 USD
Availability: PreSale

ITEM #: PLK-PS-610 MFG #: PS-610

PureLink

Our Price:

$3,499.99

Add to Wish List Leasing Options

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info

Notify when in stock

Report Lower Price Large Quantity Quote

Required Accessories

Recommended Accessories

PS-610 - Overview

The PureLink PS-610 is a 6x1 HDMI/USB-C 4K60 Seamless Presentation Switch, featuring versatile input options including USB-C, HDMI, Analog, and Dante™ 2-channel in/out audio. Additionally, it offers balanced analog audio embedding and de-embedding capabilities. Any five sources can be output in a Multiview configuration four at a time (sixth local RX HDMI input is not available for multiview). Equipped with user-friendly control options including Front Panel, IR control, RS-232, TCP/IP, Web GUI control, iCONT and other third party control drivers for popular control systems are also available.

The PS-610 is rich with commands including, switching, multiview, audio adjustments, front panel lockout, and more.

Couple the PS-610 with their iCON Control System for easy implementation of Video/Audio/IR/RS232 matrixing and control of your space.

Features:
- 6x1 Seamless Switching and Multi-View for Up to Four Sources
- USB-C supports ALT-DP mode for A/V / USB 2.0 / 60W charging
- HDBaseT™ 3.0 output Extension up to 132ft (40m) for 4K60, and up to 230ft (70m) for 1080P60
- and 4K30 signals with Included Receiver via Cat6a
- Dante™ 2x2 audio input / output
- HDMI / HDBaseT™ 3.0 mirrored output
- HDMI 2.0b / HDCP 2.2 / DP 1.2 / 18Gbps / 4K@60Hz 4:4:4
- Auto or manual switching mode
- Embedding and De-embedding of Balanced Analog Audio
- CEC/RS-232 display On / Off control
- Full screen/PIP/PBP / Multi-view/Quad-view display modes
- Local USB 2.0 KVM switching and extension.
- PoH (Power Over HDBaseT™) allows for powering Receiver (RX) from Transmitter (TX)
- Comprehensive EDID management
- Control via Front panel buttons / Handheld Remote / iCON™ / RS-232 / CEC / TCP/IP / Third Party Control Automation, and Web GUI
Specifications:
- Inputs:
  - 4x HDMI
  - 1x Display Port [Type-A]
  - 1x VGA [15-pin female]
  - 1x USB-C [Type-C USB 3.0]
- Outputs:
  - 2x HDMI
  - 1x HDBaseT [RJ45]
- Control Ports:
  - 1x RS232 [3-pin terminal block]
  - 2x Relay [3-pin terminal blocks]
  - 1x IR Eye [3.5mm jack]
  - 2x IR in [3.5mm jacks]
  - 1x IR out [3.5mm jack]
  - 1x TCP/IP [RJ45]
  - 1x Firmware [Type-A USB]
- Audio Input Type(s):
  - 1x External balanced audio (L+R) for 1-HDBT input port [5-pin terminal block]
  - 1x External balanced audio (L+R) for 2-HDBT input port [5-pin terminal block]
  - 1x External balanced audio (L+R) for 3-HDBT input port [5-pin terminal block]
  - 1x Stereo auxiliary audio for 6-VGA input port [3.5mm jack]
  - 1x Balanced MIX audio [5-pin terminal block]
- Audio Output Type(s):
  - 1x Balanced audio (L+R) for 1-HDMI output audio de-embedding [5-pin terminal block]
  - 1x Digital SPDIF audio (L+R) for 1-HDMI output audio de-embedding [Toslink connector]
  - 1x Balanced audio (L+R) for 2-HDBT output audio de-embedding [5-pin terminal block]
  - 1x Digital SPDIF audio (L+R) for 2-HDBT output audio de-embedding [Toslink connector]

  Reliability & Environmental
- Operating Temperature: 32° ~ 117° F (0° to 47° C)
- Storage Temperature: - 40° ~ 158° F (-40° to 70° C)

  Enclosure
- Enclosure Type: All metal, black powder coat finish
- Product Dimensions:
  - TX: 2.00" x 8.66" x 5.91" (44mm x 220mm x 150mm)
  - RX: 1.00" x 5.51" x 4.13" (21.5mm x 140mm x 105mm)
Item Includes:
- 1x 6x1 Seamless Presentation Switch
- 1x HDBaseT Receiver
- 1x IR Blaster Cable (1.5 meters)
- 1x IR Wideband Receiver Cable (1.5 meters)
- 2x 3 pin-3.5mm Phoenix Connector (male)
- 3x 5 pin-3.5mm Phoenix Connector (male)
- 4x Mounting Ear
- 8x Machine Screws for mounting ears
- 1x 24V/8A Desktop Power Supply & 1x AC Power Cord (1.5 meters)
- 1x IR Remote
- 1x User Manual
Warranty:
- 5-Years
