Riedel MN-HorizoN-8-RF MediorNet Hybrid Video Processor - 8 Processing Engines - 12G / 3G / HD - Rear to Front Cooling

ITEM #: RI-9300789 MFG #: MN-HORIZON-8-RF

Primary Image
  • Product Image Thumbnail 1 of 3
  • Product Image Thumbnail 2 of 3
  • Product Image Thumbnail 3 of 3
Free Shipping with $49 Minimum Order

Our Price:

$29,625.00

Availability: In Stock - Ships Factory Direct, Typically in 6 Business Days.
Please Email, Chat or Call (800) 522-2025
iAvailability Description Popup


MN-HORIZON-8-RF - Overview

Riedel's MN-HorizoN-8-RF blurs the boundary between traditional SDI-based and ST 2110 infrastructures with its dense array of SDI-IP gateways and offers an incredible amount of video processing capabilities such as up/down/cross, SDR-HDR conversion and color correction. Within a single rack unit, 8 independent and individually configurable processing engines. SFP-based baseband video I/O completes the package, making it an extremely versatile solution that can handle even the toughest challenges in a modern production environment.

  • Features:

    • 8x processing engines, e.g. for UDX, SDR/HDR conversion, Color Correction and ST 2110 IP Gateways
    • Rear to front cooling
    • 4x 100G highspeed links
    • 4x 100G IP Interfaces (2022-7)
    • 8x 12G/3G/HD/SD - SDI In & 8x 12G/3G/HD/SD SDI Out
    • Sync reference In/Out (BB, Tri-Level, WC)
    • Integrated processing incl. sample rate conversion, frame sync, test pattern generator

  • Specifications:

    • MediorNet TDM Links: 400G (16x 25G)
    • SDI Video I/O:
      - 8x IN (up to 12G)
      - 8x OUT (up to 12G)
    • Video Sync:
      - 1x I/O switchable
      - 1x Out
    • Integrated MediorNet Processing: Available on all video ports
    • MediorNet Apps: Standard App (UDX, HDR, ST 2110 IP Gateway)
    • Additional Connectivity: 8x 25 GE ST 2110 IP Interfaces (ST2022-7)
    • Redundant Power Supply: 2x Wide Range AC PSU
    • Power Consumption: 350W
    • Dimensions (LxWxH): 19" x 19.7" x 1.7" (478mm x 500mm x 44mm)
    • Weight: 22lbs (10kg)

  • Item Includes:

    • 1x MN-HorizoN-8-RF

  • Warranty:

    • 2 Year Limited Warranty
