SmallHD SMALL-MON-1303HDR Full HD 13-Inch LCD Monitor with 1500 NITs Brightness

ITEM #: SMHD-MON-1303HDR MFG #: SMALL-MON-1303HDR

  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
free ship

Our Price:

$3,999.00

Availability: Typically Ships in 3-10 Days
iAvailability Description Popup


    SMALL-MON-1303HDR - Overview

    Clarity that produces certainty.
    The display size, resolution, and pixel density of the 1303 production monitor make it an invaluable tool for precision focus pulling. When you don't have the time or proper measurements, a razor-sharp, low latency display will help you hit your marks.

    Calibrated for collaboration.
    Preview what you're sending downstream using the Output Preview Page, while utilizing software features like customizable focus assist and peaking on your 1303 monitor. If it's the only monitor near by, its color accuracy (100% REC 709) and broad viewing angle make it easy to share with clients and directors.


    Can you see me now? Good.
    With a panel roughly 3x brighter than most production monitors, the 1303 is not restrained by ambient light. Its optically bonded LCD combats glare and sunlight, allowing you to pull focus in less than ideal shooting environments.

    Proper power options.
    Power options for the 1303 monitor are simple and convenient. The 2-pin LEMO out allows for a seamless integration with accessories such as the Teradek Bolt wireless receiver.

    Travel made easy: carry-on accessories.
    All SmallHD production monitors are equipped with the Rapid Rail Mounting System; the simplest way to connect, store, and travel with critical monitor accessories.

    Smooth is fast.
    Transitioning from table to C-Stand happens safely and securely with the 1303's VESA compatible mounting accessory.


    Boldly go.
    The 1303 monitor is the perfect blend of functionality and portability. With a razor-sharp display and a rugged build quality, the 1303 will boldly go where no other production monitor has ever gone before.

    • Specifications:

      • Display
      • Panel Type: IPS
      • Size Diagonal: 13
      • ResolutionP: 1920x1080
      • Pixel Density (PPI): 170 PPI
      • Aspect Ratio: 16:9
      • Active Area: 11.59" x 6.52"
      • Brightness: 1500 nits
      • Contrast: 1140:1
      • Color Gamut: 100% Rec.709
      • Color Depth: 10­ bit
      • Viewing Angle: 178 Deg.
      • Backlight Type: LED
      • Adjustable Backlight: Yes
      • Temperature Adaptive Color: No

        Connector Type
      • SDI: 2x 3G Inputs, 2x 3G Outputs
      • HDMI: 1x Input, 1x Output
      • Component: Not Supported
      • Composite: Not Supported
      • Audio: 1x Headphone Jack on Front of Monitor
      • Power In: 1x XLR 4­pin Input 12­34VDC, 1x Lemo Output 12VDC @ 4A Max
      • Power Out: 1x XLR 4­pin Input 12­34VDC, 1x Lemo Output 12VDC @ 4A Max
      • USB: 1x Front USB2, 2x Rear USB2

        Controls
      • Primary Control Interface: Joystick Navigation, Dedicated Back Button. Additional Dedicated buttons for: Image Capture; LUT Selection; Backlight Level; Input Selection; Scopes Toggle.
      • Record/Capture: Dedicated Image Capture Button on Front Bezel
      • User Defined Functions: N/A
      • RF Wireless Remote / External Control: N/A
      • USB Remote / External Control: N/A

        Data I/O
      • Storage: SD Card for LUTs, Captured Images, Image Overlays, Profile Saving & Loading, Firmware Upgrades
      • USB: 1 Front & 2 Rear USB Ports for power (1.5A shared total), LUT Loading, Profile Saving & Loading
      • Wireless: N/A
      • Wifi: N/A

        Power
      • Connector Type: 1x XLR 4-pin 12 - 34VDC IN; 12V Lemo 2-pin OUT 4A Max
      • Voltage: 12 - 34VDC
      • Power Consumption: 25 - 39W
      • Recommended Power Supply: AC - DC Power Converter “Brick" Included with Monitor 110 - 240VAC 50 - 60 HZ INPUT; 15V - 6A OUTPUT
      • Battery Types: Gold Mount / V­Mount via 4­pin XLR Connector
      • Output Voltage (VDC): 12V, 2A max via LEMO Connector

      • Weight (Item Only without battery): 128oz
      • Weight (Packaged): 12lb

    • Item Includes:

      • 1x - 1303 HDR Production Monitor
      • 1x - 36-Inch HDMI to HDMI Cable
