Thor Fiber H-4ASI-DVBS2 4-Channel ASI to DVB-S2 Satellite Encoder Modulator
  • Thor Fiber H-4ASI-DVBS2 4-Channel ASI to DVB-S2 Satellite Encoder Modulator
  • Thor Fiber H-4ASI-DVBS2 4-Channel ASI to DVB-S2 Satellite Encoder Modulator
Questions? Ask a Markertek Expert:
800-522-2025 Email

Thor Fiber H-4ASI-DVBS2 4-Channel ASI to DVB-S2 Satellite Encoder Modulator

Manufacturer: Thor Fiber

Item #: THR-4ASI-DVBS2   •   MFG #: H-4ASI-DVBS2


List Price:$7,493.75
Our Price:$5,995.00

free ship
Availability: Direct Ship From Manufacturer
Item ships directly from the manufacturer. Normal delivery time is 2-7 business days and is subject to manufacturer availability. Need it sooner? Call 800-522-2025, or email Customer Service for expedited delivery options.
  • 2 - 7 Day Normal Delivery Time - Faster Shipping Options at Checkout or Call Us.



Designed for the highest possible reliability in digital satellite news gathering or DVB-S2 broadcast. Provides 4 ASI inputs (1+3 Fall over) as well as redundant power supplies that function in either hot or cold standby modes. The primary ASI input is constantly monitored by the system for faults in the signal, and can be programmed to transparently switch from one ASI input to another when signal loss or broken video is detected. This allows a user to implement multiple redundant encoders in an auto recovering configuration without the need for additional fall over systems. The modulator system is designed around the second generation DVB-S2 modulation protocol. This platform is able to realize all of the new advanced features not previously found under the DVB-S protocol. Most notably this system supports the highest bandwidth modulation via support for 32APSK constellations. Industry standard BISS encryption support is provided to secure digital transmissions and prevent unauthorized access to live feeds. Network management is provided for configuration and monitoring. In addition to DVB-S2 satellite RF, the processed program transport streams are also made available on UDP outputs with support for both unicast and multicast IGMP streaming.

  • Features

    • Distribut ASI program streams with redundancy over Satellite RF
    • Latest Generation program stream modulator 32PSK
    • Controlled through web server on separate network port
  • Specifications

    • ASI Input: SPTS, MPTS (up to 80Mbps)
    • ASI Output: SPTS, MPTS (up to 80Mbps)
    • RF Output: DVB-S, DVB-S2
    • IP Management: HTTP Webserver port 80
    • Power Input: 100-240 VAC Auto Switching 35W
    • Dimensions: 482 x 300 x 44 mm
    • Weight: 3.75 kg
    • Operating Temperature: 0 - 45 C
