VigilLink VLSP-18H21S 1x8 HDMI 2.1 48Gbps 8K Distribution Amplifier - HDCP 2.3 Compliant

ITEM #: VGL-VLSP-18H21S MFG #: VLSP-18H21S

Primary Image
  • Product Image Thumbnail 1 of 4
  • Product Image Thumbnail 2 of 4
  • Product Image Thumbnail 3 of 4
  • Product Image Thumbnail 4 of 4
VigilLink
Free Shipping with $49 Minimum Order

Our Price:

$407.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
  • Special Order Item: non-cancelable, non-returnable, non-refundable.
Report Lower PriceLarge Quantity Quote

VLSP-18H21S - Overview

VigilLink VLSP-18H21S 1x8 HDMI Splitter is an advanced solution for splitting single HDMI signal to 8 HDMI outputs synchronously, with video resolution up to 8K @ 60 4:2:0 12bit. It supports data rates up to 48Gbps, complying with HDMI 2.1 and HDCP 2.3 requirements. It includes several features for ease of integration, including EDID management, cable equalization. This multi-functional product can work well with xbox or PS5 to achieve 4K @ 120Hz on your TVs or relative monitors.

  • Features:

    • HDCP 2.3 compliant
    • Supports 48Gbps FRL and 18Gbps TMDS video bandwidth
    • Supports resolution up to 8K @ 60Hz 4:2:0 12bit, 4K @ 120Hz 4:4:4 12bit, as specified in HDMI 2.1
    • Supports VRR, ALLM, QMS, QFT, SBTM, as specified in HDMI 2.1
    • Supports HDR, HDR10, HDR10+, Dolby Vision, HLG pass-through
    • Supports HDMI audio formats: LPCM 7.1CH, Dolby TrueHD, Atmos, DTS-HD Master Audio
    • Supports resolution auto downscaling on each output
    • Supports auto converting of HDR to SDR on each output
    • Advanced EDID management


  • Specifications:

      Technical
    • HDMI Compliance: HDMI 2.1
    • HDCP Compliance: HDCP 2.3
    • Video Bandwidth: 48Gbps
    • Video Resolution: Up to 8K @ 60Hz 4:2:0 12bit, 4K @ 120Hz 4:4:4 12bit
    • Color Depth: 8/10/12bit
    • Color Space: RGB, YCbCr_4:4:4, YCbCr_4:2:2, YCbCr_4:2:0
    • HDR: HDR, HDR10, HDR10+, Dolby Vision, HLG
    • Audio Formats:
      - HDMI Input/Output: LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
    • ESD Protection: IEC 61000-4-2: ±8kV (Air-gap discharge) & ±4kV (Contact discharge)

      Connections
    • Input: 1x HDMI IN (Type A, 19-pin female)
    • Output: 8x HDMI OUT (Type A, 19-pin female)
    • Control: 1x SERVICE (USB Type C, Update port)

      Mechanical
    • Housing: Metal enclosure
    • Color: Black
    • Dimensions: 9.84" x 4.09" x 1.81" (250mm x 104mm x 30mm)
    • Weight: 1.63lbs (743g)
    • Power Supply: DC 12V/2.5A
    • Power Consumption: 12.2W (Max)
    • Operating Temperature: 32°F - 104°F (0°C - 40°C)
    • Storage Temperature: -4°F - 140°F (-20°C - 60°C)
    • Relative Humidity: 20% - 90% RH (No condensation)

      Recommended HDMI Cable (In/Out)
    • 8K: 9.8ft (3m) (Ultra HDMI 2.1)
    • 4K60: 16ft(5m)
    • 4K30: 33ft (10m)
    • 1080p: 49ft (15m)
      **The use of the "Premium High-Speed HDMI" is highly recommended.


  • Item Includes:

    • 1x 48Gbps 1x8 Splitter
    • 1x 12V/2.5A Multinational Locking Power Supply
    • 2x Mounting Ear
    • 4x Machine Screw (KM3*6)
    • 1x User Manual


  • Warranty:

    • 6 Years
