BZBGEAR BG-H3GS 1080P FHD HDMI to 3G-SDI Long Distance Converter/Amplifier

ITEM #: BG-H3GS MFG #: BG-H3GS

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
BZBGEAR
Free Shipping with $49 Minimum Order

Our Price:

$49.00

Add to Wish ListLeasing Options
Availability: In Stock
iAvailability Description Popup
    Report Lower PriceLarge Quantity Quote

    BG-H3GS - Overview

    The BG-H3GS allows HDMI signals to be shown on SDI displays while ensuring a high bit rate of 2.970 Gbit/s to provide a high-resolution signal without any loss. For professionals this means that it is now easier to convert your high-definition HDMI signal with audio to SDI for long distance transmissions and display your work on SDI displays.

    The BG-H3GS supports multiple input resolutions such as 480i, 720p, 1080i, and up to 1080p60. A 1080p60 HDMI signal will convert to 3G-SDI for transmission up to 100m (328ft). For even longer range transmissions 480i will convert to SD-SDI and can be transmitted up to 300m (984ft).

    • Features:

      • 1080P/60 Support - Crystal clear images with resolutions up to 1080p@60Hz
      • Portable - Ideal for any on-the-go kit
      • Rigid Design - Durable metal structure built to withstand years of operation
      • 3G-SDI - Up to 100 meters, HD-SDI - Up to 200 meters, SD-SDI - Up to 300 meters
      • HDMI input timings: [email protected], 576i, 720p@50/59.94/60, 1080i@50/59.94/60, [email protected]/24/25/29.97/30/50/59.94/60
      • SDI Transmission Rate - 2.970 Gbit/s and 2.970/1.001 Gbit/s


    • Specifications:

      • Input Port: 1x HDMI
      • Output Port: 1x BNC (SDI/HD-SDI/3G-SDI)
      • SDI Transmission Rates: 2.970 Gbit/s and 2.970/1.001 Gbit/s
      • In/Output Resolution: 480i, 576i, 720p@50/59.94,60, 1080i@50/59.94/60,[email protected]/24/25/29.97/30/50/59.94/60
      • Power Supply: DC 5V -12V
      • ESD Protection Human body model: ±8kV (air-gap discharge), ±4kV (contact discharge)
      • Dimension: 3.1in x 1.6in x 0.98in [80mm x 41mm x 25mm]
      • Weight: 0.33 lbs [150g]
      • Operating Temperature: 32°F ~ 104°F / 0°C ~ 40°C
      • Storage Temperature: -4°F ~ 140°F / -20°C ~ 60°C
      • Relative Humidity: 20 ~ 90% RH (Non-condensing)
      • Power Consumption (Max): 5W


    • Item Includes:

      • 1x BG-H3GS HDMI to 3G SDI Converter
      • 1x 5V1A DC Power Supply Adaptor
      • 1x User Manual
