Blustream CMX42CS Contractor 4x2 4K 18Gbps HDMI 2.0 Matrix Switcher with Audio Breakout / EDID Management & IR Routing

ITEM #: BLU-CMX42CS MFG #: 9340242005564

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Blustream
Free Shipping with $49 Minimum Order

List Price:

$840.00

Our Price:

$835.00

Add to Wish ListLeasing Options
Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup
Notify when in stock
Report Lower PriceLarge Quantity Quote

9340242005564 - Overview

Engineered to handle high-performance AV signal routing in demanding installation environments

The Blustream CMX42CS is a compact yet powerful 4x2 HDMI 2.0 matrix switch delivering premium 4K video support and advanced integration capabilities, it represents unmatched value and flexibility for professional AV installers.

Supporting full HDMI 2.0 with HDCP 2.2 compliance, the CMX42CS enables the reliable distribution of up to four HDMI source devices to two independent HDMI outputs. All video resolutions up to 4K UHD at 60Hz 4:4:4 (18Gbps) are supported, ensuring full compatibility with the latest UHD and HDR content.

With its robust feature set and installer-centric design, the CMX42CS is an ideal solution for residential AV systems, boardrooms, classrooms, and multi-zone commercial environments requiring reliable 4K video distribution and system control.

  • Features:

    • Features 4x HDMI inputs which can be independently routed to 2x HDMI outputs
    • Supports HDMI 2.0 18Gbps specification including HDR
    • Supports up to 4K UHD 60Hz 4:4:4
    • Video down-conversion on outputs allowing a display only capable of supporting lower video resolutions (4K 60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on remaining video output.
    • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K.
    • Supports bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications.
    • HDMI audio breakout to associated output analogue L/R audio and coaxial digital outputs concurrently.
    • Control via front panel, TCP/IP, IR and RS-232
    • IR routing
    • Supplied with Blustream 5V IR receivers and emitters
    • 3rd Party drivers available for all major control brands
    • Advanced EDID management HDCP 2.2 support


  • Specifications:

    • Dimensions (WxDxH): 10" x 4.1" x 1.6" (255mm x 104mm x 40mm)
    • Shipping Weight: 3.5lbs (1.6kg)
    • Operating Temperature: 32°F - 104°F (0°C - 40°C)
    • Storage Temperature: -4°F - 140°F (-20°C - 60°C)
    • Video Input Connectors: 4x HDMI Type A, 19-pin, female, locking
    • Video Output Connectors: 2x HDMI Type A, 19-pin, female, locking
    • Audio Output Connectors: 2x Optical (S/PDIF), 2x Analog audio L/R (3.5mm stereo Jack)
    • TCP/IP Control: 1x RJ45, female
    • RS-232 Serial Port: DB-9, female
    • IR Input Ports: 3x 3.5mm stereo jack
    • IR Output Ports: 4x 3.5mm mono jack


  • Item Includes:

    • 1x CMX42CS
    • 1x 12V/2.5A DC Power Supply
    • 1x Remote Control
    • 4x IR Emitter
    • 3x IR Receiver
    • 1x Mounting Kit
    • 1x Quick Reference Card
