Blustream HD12DB 1x2 Splitter HDMI 18G w/Down Mixing DAC

ITEM #: BLU-HD12DB MFG #: HD12DB

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2
Blustream
Free Shipping with $49 Minimum Order

Our Price:

$688.00

Add to Wish ListLeasing Options
Availability: Ships Factory Direct, Typically in 3-10 Business Days
iAvailability Description Popup
    Report Lower PriceLarge Quantity Quote

    HD12DB - Overview

    The Blustream HD12DB has been designed to convert and downmix embedded 5.1ch Dolby Audio or DTS Audio within a HDMI signal into a stereo 2ch signal available on HDMI, optical and analog audio outputs.

    The HD12DB features a HDMI loop out to pass the original video and multi-channel embedded audio signal to compatible equipment, with a second HDMI output featuring video scaling of resolutions up to 4K @ 60Hz 4:4:4 video to various lower video formats. This provides the perfect cost-effective solution for ensuring that 4K UHD video and multi-channel audio can be distributed around a multi-room system where there are a mixture of 2ch and 5.1ch zones with multiple output resolution requirements.

    • Features:

      • Features an in-built DAC (Digital to Analog audio Converter) that converts 5.1ch Dolby Audio or DTS Audio to a stereo 2ch signal available on HDMI, optical and analog audio outputs concurrently
      • Supports the following audio input formats: Dolby 5.1, DTS-ES 6.1, DD+5.1, DD+2.0, PCM 5.1, PCM 2.0 *
      • Features 1 x HDMI input supporting 4K UHD video (4K @ 60Hz 4:4:4) that is replicated to 2x HDMI outputs
      • HDMI loop out will replicate the HDMI input signal up to 4K @ 60Hz 4:4:4 and 5.1ch Dolby Audio & DTS Audio
      • HDMI output 2 features a video scaler allowing the output resolution to be set to the following formats:
      • - 3840x2160 @ 60Hz
      • - 3840x2160 @50Hz
      • - 3840x2160 @ 30Hz
      • - 3840x2160 @25Hz
      • - 4K DCI @ 25Hz 4:4:4
      • - 4K DCI @ 30Hz 4:4:4
      • - 4K DCI @ 50Hz 4:4:4
      • - 4K DCI @ 60Hz 4:4:4
      • - 1920x1080 @ 60Hz
      • - 1920x1080 @50Hz
      • - 1280x720 @ 60Hz
      • - 1280x720@50Hz
      • - 1920x1200@ 60Hz
      • - 1680x1050@ 60Hz
      • - 1024x768@ 60Hz
      • HDMI audio breakout to downmixed analog L/R audio and downmixed optical digital outputs concurrently
      • HDCP 2.2 compliant with advanced EDID management
      • *NOTE: This product does not support decoding of DTS CD bitstreams. Playback of this format may produce undesirable noise.


    • Specifications:

      • Video Input Connectors: 1 x HDMI Type A, 19-pin, female
      • Video Output Connectors: 2 x HDMI Type A, 19-pin, female
      • Audio Output Connectors: 1 x Optical (TOSLINK), 2x RCA analog left / right
      • EDID: 4-PIN DIP switch
      • Resolution: 4-PIN DIP switch
      • Product upgrade: 2 x Micro USB female
      • Dimensions (W x H x D): 127mm x 23mm x 104mm, without feet
      • Shipping Weight: 1.0kg
      • Operating Temperature: 32°F to 104°F (0°C to 40°C)
      • Storage Temperature: -4°F to 140°F (-20°C to 60°C)
      • Power Supply: 5V/3A DC


    • Item Includes:

      • 1x HD12DB
      • 1x 5V/3A DC Power Supply
      • 1x Mounting Kit
      • 4x Rubber Feet
      • 1x Quick Reference Guide


    • Warranty:

      • 3 Year Warranty


    • GTIN:

      9340242003027
