    CUSTOMPRO-HUB - Overview

    The Blustream CUSTOMPRO-HUB Matrix achieves new levels of both performance and flexibility. AV installers can now easily specify their desired I/O structure and choose the additional control features required for a specific project. The Custom Pro Matrix has been specifically designed to operate in challenging AV environments. Its robust housing and interlocking board configuration make both installation and maintenance a seamless experience. Advanced optional features include audio breakout, simultaneous HDBaseT™/HDMI outputs, 2-way routed IR and RS-232 pass through. A web browser interface module and App for control and configuration of the matrix is included as standard as well as analog audio embedding per zone.

    • Features:

      • Custom Pro Matrix Hub with 8x modular bays for population of control & input/output boards
      • Up to 8x video inputs and 8x video outputs can be achieved using Custom Pro boards
      • 8x analog L/R audio inputs which can be embedded onto corresponding HDMI/HDBaseT™ zone outputs
      • Control of Matrix via front panel, IR, RS-232, TCP/IP and web-GUI / App
      • Supports PoH (Power over HDBaseT™) when used with compatible HDBaseT™ input/output cards
      • Web interface module for control and configuration of Matrix
      • 3rd Party drivers available for major home control brands
      • Advanced EDID management
      • HDCP2.2 compliant

    • Specifications:

      • Audio Input Connectors: 8 x 3.5mm stereo jack (L/R)
      • RS-232 serial ports: 1x 9-pin RS-232 connector
      • TCP/IP Control: 1x RJ45, female
      • Rack-Mountable: 2U rack height, rack ears included
      • Casing Dimensions (W x H x D): 440mm x 87mm x 282mm without feet
      • Casing Dimensions (W x H x D): 440mm x 94mm x 288mm with feet / connections
      • Shipping Weight: 5.0kg
      • Operating Temperature: 32°F to 104°F (0°C to 40°C)
      • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
      • Power Supply: 12V/6A DC

    • Item Includes:

      • 1x CUSTOMPRO-HUB

    • Warranty:

      • 3 Year Warranty

    • GTIN:

      9340242002075
