Belkin F1DN204KVM-UN-4 Universal 2nd Gen Secure KVM Switch - 4-Port Dual Head with CAC

ITEM #: F1DN204KVM-UN-4 MFG #: F1DN204KVM-UN-4

Primary Image
  • Product Image Thumbnail 1 of 5
  • Product Image Thumbnail 2 of 5
  • Product Image Thumbnail 3 of 5
  • Product Image Thumbnail 4 of 5
  • Product Image Thumbnail 5 of 5
Free Shipping with $49 Minimum Order

List Price:

$1,618.99

Our Price:

$1,429.99

Availability: Usually Ships in 5-14 Days.
Please Email, Chat or Call (800) 522-2025 for Detailed Delivery Info
iAvailability Description Popup


    F1DN204KVM-UN-4 - Overview

    Belkin F1DN204KVM-UN-4 is a Universal 2nd Gen 4-Port Secure KVM Switch. Utilizing an innovative display connection technology and a set of passive cables, the Belkin Universal 2nd Gen Secure KVM (SKVM) Switch can simultaneously accommodate legacy DVI-D input/output as well as modern, high-resolution HDMI and DisplayPortT input/outputs on the same SKVM. The pioneering connector design and internal video conversion allows the same SKVM to be used for legacy systems and accommodates anticipated technology changes over time, ensuring today's investment is not rendered obsolete as underlying systems get upgraded.

    This Universal 2nd Gen SKVM is the ideal solution for systems using high-performance DisplayPort graphics outputs as well as monitor inputs. The platform is fully compatible with Display Port and HDMIr connections supporting resolutions of UHD 4K @60Hz. The platform's flexibility also allows support for standard definition and HD resolutions supported by DVI-D without the need for unreliable and costly external converters. The platform is truly plug and play now and into the future.

    The Belkin Universal 2nd Gen SKVMs are designed for the latest Common Criteria and NIAP cybersecurity standard: NIAP Protection Profile for Peripheral Sharing Devices 4.0. As a comprehensive SKVM, the Belkin Universal 2nd Gen SKVM is further compliant to the Audio Input Devices module version 1.0, Keyboard/ Mouse Devices module version 1.0, Video/Display Devices module version 1.0, Audio Output Devices module 1.0 and User Authentication Devices module version 1.0. NIAP PP PSD 4.0 adds to the strict signal isolation requirements of NIAP PP PSS 3.0 and defines the latest standard for military-grade cybersecurity.

    • Features:

      • Designed for NIAP Protection Profile PSD 4.0 Compliance
      • Combo connector video support for up to 4K (3840x2160), @60hz refresh
      • Compatible with the Belkin Secure KVM Remote Control with Integrated Keyboard (Optional)
      • Customizable port coloring and naming on the front panel: Facilitates port identification and reduces user switching errors. Color coding mimicked by Belkin KVM Remote Control with Integrated Keyboard
      • Extrusion form factor that supports an under-counter mount (Optional)
      • Supports TAA combo and video cables for easy deployment
      • Supports up to four host computers
      • Supports two displays for the user
      • CAC and Audio freeze functionality
      • Dedicated processors with emulators for every port: Isolated port paths for video, audio, and peripherals prevent data leaks between computers
      • Unidirectional data paths: Optical data diodes prevent peripherals from being used to breach systems
      • Display security: Protected display interface prevents data leakage via the monitor
      • Analog audio via 3.5mm jack with ultrasonic audio filtering
      • Peripheral management: USB device detection prevents unauthorized peripheral usage
      • Active Anti-tampering and Secure labeling: Holographic tamper-evident product label provides visual indication and prevention of tampering
      • Fast switching: No keyboard or mouse delays when switching ports, minimal video delay
      • Secure packaging: Tamper-evident packaging ensures product is not tampered with during transport

    • Specifications:

      • Ports: CaC/DPP, Computers, Keyboard, Monitors, Mouse, Remote
      • Security Features: Designed for NIAP PP 4.0 Compliance
      • Storage Temperature: -4 to 140F
      • Certifications: FCC Class A UL CE RoHS ICES RCM
      • Console Ports: 1, Dual Monitors
      • Display Connection: DisplayPort/HDMI
      • Display Type: DP/HDMI
      • Form Factor: Desktop
      • Host Ports: 4
      • Keyboard Input: 1
      • Keyboard/Mouse Connections: 2
      • Keyboard Type: USB
      • KVM Maximum Resolution Supported: 4K@60hz
      • Local Console Interfaces: 1, Dual Monitors
      • Maximum Resolution: 4K@60hz
      • Mouse Input: 1
      • Mouse Type: USB
      • PC Ports: 4
      • Power Rating: 12VDC 2.5A
      • Power Supply Included: Yes
      • Power Supply Type: External
      • Remote Control Included: No
      • Supported Audio Formats: 3.5mm Analog
      • Supported Video Formats: DisplayPort/HDMI
      • TAA Compliant: Yes

    • Item Includes:

      • 1x Belkin F1DN204KVM-UN-4 Secure Universal 2nd Gen 4-Port, Dual Monitor Switch
      • 1x 12V, 2.5A Universal Power Supply with Worldwide Adaptors
      • 1x Port Naming Labels
      • 1x Quick Start Guide and Compliance Documentation
