KanexPro EXT-4KHD150M2 18G Premium HDMI Extender Kit - Tx/Rx - up to 150M over CAT6 - HDBT Compatible

ITEM #: KAN-EXT4KHD150M2 MFG #: EXT-4KHD150M2

Primary Image
Free Shipping with $49 Minimum Order

Our Price:

$379.95

Availability: Typically Ships in 3-10 Business Days
iAvailability Description Popup


    EXT-4KHD150M2 - Overview

    The KanexPro EXT-4KHD150M2 is a powerful audio video extender that allows you to extend your 4K video signal up to a distance of 150 meters (492 feet). This extender supports resolutions of up to 4K2K@60Hz 4:4:4 and has a data rate of 18Gbps, making it ideal for use in a variety of settings where high quality video is required.

    In addition to its video capabilities, the EXT-4KHD150M2 also supports audio de-embedding and has a built-in two-way IR pass-through, allowing you to control your source and display from a distance.

    Audio video extenders like the KanexPro EXT-4KHD150M2 can be used in a variety of settings, including churches, classrooms, and presentation halls. In a church setting, an extender like this one can be used to transmit audio and video signals from the pulpit to the front of the house, allowing worshipers to experience the service in high definition. In a classroom or presentation hall, an extender can be used to transmit video from a remote source to a display, reducing the need for complex cabling and repeaters.

    Overall, the KanexPro EXT-4KHD150M2 is a versatile and reliable audio video extender that is well-suited for use in a wide range of settings. With its long range and professional performance, it is an excellent choice for anyone in need of high quality video transmission

    Applications:
    Court Rooms
    Classrooms
    Conference Rooms or Showrooms where audio-visual & control devices can be extended from a remotely located HDMI sources.
    Professional Performance

    • Features:

      • HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant
      • Support 18Gbps video bandwidth
      • The maximum extended transmission distance via a single Cat5e/6 cable: 394ft / 120 meters for 4K2K signal; 492ft / 150 meters for 1080P signal
      • Support one HDMI loop output on the transmitter
      • Extract audio to analog stereo output on receiver
      • With bi-directional IR, RS-232 and CEC pass-through
      • HDR, HDR10+, Dolby Vision and HLG function supported
      • Support PoC (Power over Cable)
      • Compact design for easy and flexible installation
      • Covered by KanexPro's 3 year limited product warranty

    • Specifications:

      • Technical Performance:
      • HDMI Compliance: HDMI 2.0
      • HDCP Compliance: HDCP 2.2
        Video Bandwidth:
      • HDMI: 18 Gbps
      • HDMI Supported Resolutions: Up to 4K2K@50/60Hz(YCbCr 4:4:4),[email protected] HDMI 3D TV format, etc.
      • Color Space: RGB, YCbCr4:4:4,YCbCr4:2:2, YCbCr 4:2:0
      • Supported Audio Formats:100-240V , 50/60Hz, 0.3A
      • Transmission Distance: Max distance (4K) : 394ft/120m overCAT5e/6 Max distance (1080p) : 492ft / 150m over CAT5e/6

        Transmitter
        Inputs:
      • 1x HDMI Type A (19-pin female)
      • 1x IR IN (3.5mm Stereo Mini-jack)
        Outputs:
      • 1x HDMI Type A (19-pin female)
      • 1x Premium Extender OUT (RJ45)
      • 1x Service (Mini-USB)
      • 1x IR OUT (3.5mm Stereo Mini-jack)

        Receiver
        Input Ports:
      • 1 x CAT6 IN (RJ45, 8-pin female)
      • 1x IR IN (3.5mm Stereo Mini-jack)
        Output Ports:
      • 1 x HDMI Type A (19-pin female)
      • 1 x IR OUT (3.5mm Stereo Mini-Jack)
      • 1 x Service (Mini-USB, Update Port)
      • 1 x AUDIO OUT (3.5mm Stereo Mini-Jack)

        Power Supply:
      • Input: AC 100- 240v 50/60Hz
      • Output: DC24v/1.0A (locking Connector)
      • POC (Power over Cable) Transmitter to Receivers

        Operating Environment:
      • Operating Temperature: 32° to 104°F (0° to 40°C)
      • Storage Temperature: -4° to 140°F (-20° to 60°C)
      • Relative Humidity: 20 to 90% RH

        Mechanical Properties
        Dimensions (WxDxH):
      • Transmitter: 5.51 x 2.56 x 0.71" (140 x 65 x 18mm)
      • Receiver: 5.51 x 2.56 x 0.71" (140 x 65 x 18mm)
      • Housing: Metal Enclosure
      • Color: Black
        Weight:
      • Transmitter: 1.88Lbs 853g)
      • Receiver: 0.54Lbs (246g)

    • Warranty:

      • 3 Year parts and labor
