Kramer PT-101UHD 4K60 4:2:0 HDMI HDCP 2.2 Repeater

ITEM #: KR-PT-101UHD MFG #: PT-101UHD

Primary Image
  • Product Image Thumbnail 1 of 2
  • Product Image Thumbnail 2 of 2

This item is no longer available.
Ask a Markertek Expert if you need assistance finding an appropriate substitute.

(800) 522-2025Email

Items similar to the KR-PT-101UHD

PT-101UHD - Overview

Range 4K@60Hz (4:2:0) - 20m (66ft)

The Kramer PT-101UHD is a high-performance repeater/extender for 4K@60Hz (4:2:0) HDMI and HDCP 2.2 signals. The unit can extend the range up to 20m (66ft) for 4K@60Hz (4:2:0) signals.

Perfect for:
Home theater, presentation and multimedia applications
Rental and staging
Education and corporate

  • Features:

    • Range Extension - 4K@60Hz (4:2:0) up to 20m (66ft) (15m on the input to the PT-101UHD and 5m on the output).
    • Max. Data Rate - 10.2Gbps (3.4Gbps per data channel).
    • Re-clocking and Equalization.
    • HDMI Output Power Follows Input - There is no power on the output when there is no active input.
    • Transparent HDCP 2.2 Support.

  • Specifications:

    • INPUT
    • 1 HDMI on an HDMI connector

    • OUTPUT
    • 1 HDMI on an HDMI connector

    • BANDWIDTH
    • Supports up to 10.2Gbps (3.4Gbps per graphic channel)
    • supports up to 4K@60Hz (4:2:0) including WUXGA and 1080p 36-bit Deep Color

    • CONTENT PROTECTION
    • HDCP

    • INDICATORS
    • ON LED indicates power and/or HDMI signal

    • POWER SOURCE
    • 5V DC, 230mA

    • OPERATING TEMPERATURE
    • 0° to +40°C (32° to 104°F)

    • STORAGE TEMPERATURE
    • -40° to +70°C (-40° to 158°F)

    • HUMIDITY
    • 10% to 90%, RHL non-condensing

    • COOLING
    • Convection

    • ENCLOSURE TYPE
    • Aluminum

    • VIBRATION
    • ISTA 1A in carton (International Safe Transit Association)

    • REGULATORY COMPLIANCE
    • CE

    • ENVIRONMENTAL REGULATORY COMPLIANCE
    • RoHs and WEEE

  • Item Includes:

    • PT-101UHD 4K UHD HDMI Repeater
    • Power Supply (5vDC)
    • Bracket Installation Kit
    • Rubber Feet (4)

  • Warranty:

    • Limited 7 Year Warranty

  • GTIN:

    7291063074579
